Page 1: Installation Guide
SMCWTVG Wireless Travel Voice Gateway Installation Guide The easy way to make all your network connections 38 Tesla Irvine, CA 92618 March 2006 Phone: (949) 679-8000 Revision Number: R01 F1.0.6.x... - Page 2 SMC Networks, Inc. 38 Tesla Irvine, CA 92618 All rights reserved. Trademarks: SMC is a registered trademark; and EliteConnect is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
-
Page 3: Federal Communication Commission Interference Statement
Compliances Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 4 EC Conformance Declaration Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following conformance standards: • EN 60950-1 (IEC 60950-1) - Product Safety • EN 300 328 - Technical requirements for 2.4 GHz radio equipment •...
-
Page 5: Table Of Contents
Contents Chapter 1: Introduction Package Checklist Hardware Description Component Description Chapter 2: Connecting the Wireless Travel Voice Gateway Internet Gateway Wireless Client Wireless Access Point VoIP Telephony Functions Appendix A: Troubleshooting Diagnosing LED Indicators Appendix B: Cables and Pinouts Twisted-Pair Cable Assignments 10/100BASE-TX Pin Assignments Straight-Through Wiring Crossover Wiring... - Page 6 Contents...
-
Page 7: Chapter 1: Introduction
Chapter 1: Introduction The Wireless Travel Voice Gateway SMCWTVG is a compact multi-funtion network connection device. The unit provides secure wired and wireless high-speed data and VoIP (Voice over Internet Protocol) communications through an Internet connection. The Wireless Travel Voice Gateway functions in the following operating modes: •... -
Page 8: Hardware Description
Introduction Hardware Description Top Panel Side Panels LINE Port WAN Port Power Socket PHONE Port LAN Port Factory Default Reset Button... -
Page 9: Wan Port
Hardware Description Component Description WAN Port The Wireless Travel Voice Gateway’s WAN port is a standard RJ-45 Ethernet network port. It is for connecting the gateway to an Internet connection device, such as an ADSL or cable modem. You can also connect the WAN port to a switch in an Ethernet network that provides Internet access. -
Page 10: Led Indicators
Introduction LED Indicators The Wireless Travel Voice Gateway includes three system status LED indicators and two port LED indicators for each of the LAN and WAN ports, as described in the following figures and tables. Wireless Power/Diag Internet Status Description Power/Diag On Green Indicates that the system is working normally. -
Page 11: Power Connector
Hardware Description Link/Activity Speed Status Description Right On Green Indicates a valid network link on the port. (Link/Activity) Flashing Green Indicates network activity on a port link. There is no valid network link on the port. Left On Amber Indicates the port is operating at 100 Mbps. (Speed) Indicates the port is operating at 10 Mbps. - Page 12 Introduction...
-
Page 13: Chapter 2: Connecting The Wireless Travel Voice Gateway
Chapter 2: Connecting the Wireless Travel Voice Gateway In its default setting, the Wireless Travel Voice Gateway’s operating mode is determined by how it is connected. The Gateway and Wireless Client modes are automatically implemented depending on the WAN port connection. The Access Point mode, as well as VoIP functions, require manual configuration using the Wireless Travel Voice Gateway’s web management interface. -
Page 14: Wireless Client
Connecting the Wireless Travel Voice Gateway Power on the Wireless Travel Voice Gateway by connecting the AC power adapter and plugging it into a power source. Use your PC’s web browser to access the Wireless Travel Voice Gateway’s management interface and run the Setup Wizard to make any configuration changes (refer to the Management Guide for details). -
Page 15: Wireless Access Point
Wireless Access Point To connect the Wireless Travel Voice Gateway for use as a wireless client, follow these steps: Connect an Ethernet cable from the Wireless Travel Voice Gateway’s LAN port to your PC. Power on the Wireless Travel Voice Gateway by connecting the power adapter to a nearby power source. - Page 16 Connecting the Wireless Travel Voice Gateway Notebook PC Connect AC power Wireless Travel adapter to Voice Gateway power source (Default IP 192.168.2.1) Connect LAN or WAN port to Ethernet LAN switch Internet Connect to web Server interface from LAN PC and use Setup Wizard to configure Desktop PC access point service...
-
Page 17: Voip Telephony Functions
VoIP Telephony Functions VoIP Telephony Functions The Wireless Travel Voice Gateway can function as a VoIP gateway for making telephone calls over the Internet. Using the Internet to make VoIP calls to any other VoIP user in the world is essentially free, and even calls to regular PSTN (Public Switched Telephone Network) phones are much cheaper than making a traditional long distance calls. - Page 18 Connecting the Wireless Travel Voice Gateway you want to use (see the appropriate section in this chapter), then follow these steps: Connect an RJ-11 telephone cable from the Wireless Travel Voice Gateway’s PHONE port to your standard (analog) telephone set. Connect an RJ-11 telephone cable from the Wireless Travel Voice Gateway’s LINE port to an available PSTN telephone jack.
-
Page 19: Appendix A: Troubleshooting
Appendix A: Troubleshooting Diagnosing LED Indicators Troubleshooting Chart Symptom Action Power LED is Off • AC power adapter may be disconnected. Check connections between the Wireless Travel Voice Gateway, the power adapter, and the wall outlet. Power LED is Amber for more •... - Page 20 Troubleshooting...
-
Page 21: Appendix B: Cables And Pinouts
Appendix B: Cables and Pinouts Twisted-Pair Cable Assignments For 10/100BASE-TX connections, a twisted-pair cable must have two pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes. Also, an RJ-45 connector must be attached to both ends of the cable. -
Page 22: Straight-Through Wiring
Cables and Pinouts Table B-1. 10/100BASE-TX MDI and MDI-X Port Pinouts MDI-X Signal Name MDI Signal Name Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-) Transmit Data plus (TD+) Receive Data plus (RD+) Transmit Data minus (TD-) Receive Data minus (RD-) 4,5,7,8... -
Page 23: Rj-11 Ports
RJ-11 Ports RJ-11 Ports Standard telephone RJ-11 connectors and cabling can be found in several common wiring patterns. These six-pin connectors can accommodate up to three wire pairs (three telephone lines), but usually only one or two pairs of conductor pins and wires are implemented. - Page 24 Cables and Pinouts...
-
Page 25: Appendix C: Specifications
Appendix C: Specifications Physical Specifications Ports 2 10/100BASE-TX ports, RJ-45 connector, auto MDI/X 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) 1 FXS port (PHONE), RJ-11 connector 1 FXO port (LINE), RJ-11 connector LED Indicators Power, Internet, Wireless (802.11b/g Wireless Link/signal strength), WAN (Ethernet Link/Activity, Speed), LAN (Ethernet Link/Activity, Speed) -
Page 26: Wireless Specifications
Specifications Wireless Specifications Maximum 802.11b/g Channels FCC/IC: 1-11 ETSI: 1-13 France: 10-13 MKK: 1-14 Operating Frequency 2.4 ~ 2.4835 GHz (US, Canada, ETSI) 2.4 ~ 2.497 GHz (Japan) Maximum Wireless Clients Data Rate 802.11g: 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps (automatic fall back) 802.11b: 1, 2, 5.5, 11 Mbps (automatic fall back) Modulation Type 802.11g: CCK, BPSK, QPSK, OFDM... -
Page 27: Compliances
Compliances Call Features Call transfer Call waiting/hold/retrieve 3-way conference call Call-ID number and name Call-ID block Anonymous call blocking T.38 fax relay Dial plan (E.164 dialing plan) Do not disturb setting Speed dial Repeat dialing on busy Call return Call forwarding: No Answer/Busy/All Distinctive ringing Compliances Emissions... - Page 28 Specifications Shock IEC 68-2-29 Drop IEC 68-2-32 Safety UL/cUL (UL 60950-1) IEC 60950-1 (CB) Standards IEEE Std. 802.3-2002 10BASE-T and 100BASE-TX IEEE 802.11b, g Wi-Fi 11b/g, WPA, WPA2, WMM UPnP...
- Page 30 Model Number: SMCWTVG Pub. Number: 150200025700E, E032006-R02...
