SMC Networks SMCD3GN2 User Manual page 12

LED Color
POWER Green
DS Green
Blue
DS and US
US Green
Blue
ONLINE Green
ETH 1 – ETH 4 Green
Blue
WIFI Green
USB Green
Getting to Know Your Gateway
Table 1. Front Panel LEDs
ON = power is supplied to the Gateway.
OFF = power is not supplied to the Gateway.
Blinking = scanning for DS channel.
ON = synchronized on 1 channel only.
ON = synchronized with more than 1 channel (DS Bond mode).
Both DS and US blinking together = operator is performing maintenance.
Blinking = ranging is in progress.
ON = ranging is complete on 1 channel only.
OFF = scanning for DS channel.
ON = ranging is complete, operate with more than 1 channel (US Bond mode).
Blinking =.cable interface is acquiring IP, ToD, CM configuration.
ON = Gateway is operational.
OFF = Gateway is offline.
Blinking = data is transmitting.
ON = connected at 10 or 100 Mbps.
OFF = no Ethernet link detected.
Blinking = data is transmitting.
ON = connected at 1 Gbps.
OFF = no Ethernet link detected.
Blinking = data is transmitting.
ON = Wi-Fi is enabled.
OFF = Wi-Fi is disabled.
Reserved for future use.
