SMC Networks SMCD3GN2 User Manual page 78

Table 18. Predefined Access Rules Menu Options
Option
Service
Remote IPs
Start IP
End IP
Local IPs
Start IP
End IP
Configuring Your Gateway
List of predefined services from which you can choose.
Allows access to any remote IP address, one remote IP address, or a range of remote IP
addresses.
If you select one remote IP address, enter the IP address in the Start IP field.
•
If you select a range of remote IP addresses, enter the starting IP address in the Start IP
•
field and the ending IP address in the End IP field.
To forward to:
A single remote IP address, enter the remote IP address.
•
• A range of remote IP addresses, enter the starting IP address here and the ending IP
address range in the next field.
This field is unavailable if the Gateway is configured for any remote IP addresses.
Enter the ending IP address in the remote IP address range. This field is unavailable if the
Gateway is configured for any remote IP addresses or for a single remote IP address.
Lets you specify any local IP addresses, a single local IP address, or a range of local IP
addresses to which the access rule is applied.
• If you select one local IP address, enter the IP address in the Start IP field.
If you select a range of local IP addresses, enter the starting IP address in the Start IP field
•
and the ending IP address in the End IP field.
To apply the predefined access rule to:
A single local IP address, enter the local IP address.
•
A range of local IP addresses, enter the starting IP address here and the ending IP address
•
range in the next field.
This field is unavailable if the Gateway is configured for any local IP addresses.
Ending IP address in the local IP address range to which the access rule will be applied. This
field is unavailable if the Gateway is configured for any local IP address or a single local IP
address.
78
SMCD3GN2 Wireless Cable Modem User Manual
Description
