Port Based Qos Menu - SMC Networks SMCD3GN2 User Manual

Port Based QoS Menu

The Port Based QoS menu lets you enable or disable the Gateway's port-based QoS
setting. To access the Port Based QoS menu, click QOS in the menu bar and then click the
Port submenu in the menu bar. Figure 24 shows an example of the menu.
To enable the Gateway's port-based QoS setting, check Enable Port Based QoS and
click Apply.
To disable the Gateway's port-based QoS setting, uncheck Enable Port Based QoS
and click Apply.
Note: The Port submenu is not available in the menu bar if Enable QOS Module is not
checked in the QoS Settings menu (see page 39).
Configuring Your Gateway
Figure 24. Port Based QoS Menu
45
SMCD3GN2 Wireless Cable Modem User Manual
