mBOX600 User's Manual
1.2.3

System Specification

⚫ Watchdog Timer
◼ 1~65535 seconds; up to 65535 levels.
⚫ Power Supply
24V DC in see "1.5 Packing List" for power adapter detail information.
◼
⚫ Operation Temperature
◼ 0°C to +40°C (+32°F to 104°F).
⚫
Humidity
◼ 10%RH ~ 90%RH (non-condensing).
⚫ Vibration Endurance
◼ 3 grms STD, random 5~500Hz, 1hr/axis.
⚫ Weight
◼
4 kg (8.82 lb) without package
⚫ Dimensions
◼ 250 mm (9.84") x 240 mm (9.44") x 90 mm (3.54")
1.2.4

Driver CD Content

Please download system drivers and user's manual from Axiomtek website.
⚫ Chipset
⚫
Ethernet
⚫ Graphic
®
⚫ Intel ME
⚫ Serial Patch
All specifications and images are subject to change without notice.
Note
4 Introduction
