Removing The Shipping Locks - Compuprint Z03 User Manual

Tractor Area
Cover
Figure 1. Locating Printer Parts

Removing the shipping locks

1. Open the tractor area cover and make sure that you remove the shipping locks,
6
Quick Setup Guide
Front View
Operator
Attention
Panel
Light
Printer Cabinet (option)
Printer Handgrip
Rear View
Controller Board and
Interface Connectors
including the two knurled lock screws which hold the tractor in place. Store the
locks with the packing material.
Ribbon Lift Assembly
Upper Printer
Cover
Power Connector
Inside View
Print Head
Ribbon Cartridge Supports
Left Side View
C8Q10001
Power Switch
Paper
Bail
