Display Message
003 FORMS EJECTED
PRESS LOAD
003 FORMS EJECTED
005 MARGIN ERROR
ADJ MARGIN/LINE LENGTH
009 INVALID KEY PRESS
009 INVALID KEY PRESSES
009 INVALID KEY PRESS
PRESS STOP FIRST
014 INVALID FORMS SELECT
ADD PATH OR PRESS START
014 XXXXXXXX
ADD PATH OR PRESS START
The device requested by the job being
sent is not installed in the printer. The
above messages alternate at one second
intervals where XXXXXXXX tells the
requested forms device which can be
Front or Rear.
020 FORMS JAMMED REAR
CLEAR JAM RELOAD FORMS
026 HEX PRINT ACTIVE
32
Quick Setup Guide
Recovery Action
Auto Restore is set to Disabled and an Eject has moved the form up to
the Tear Bar. The printer is waiting. This is most likely to occur during a
tear off operation. Tear the forms at the perforation at the Tear Bar. Then
a manual Restore must be done by pressing LOAD/EJECT.
If the Processing light is blinking, the next job has already been
received and is pending.
Auto Restore is set to Data or Timer and an Eject has moved the form
up to the Tear Bar. The printer will restore the form automatically either
when the next job is received (Auto Restore = Data) or after a defined
time elapses (Auto Restore = Timer).
1. Press STOP.
The left margin automatically resets to 10 units (see Chapter 11,
"Printer Adjustments" in the User's Guide
2. Press START.
1. Check the operator panel function.
2. Reenter the correct operation.
See "Checking and Changing Configuration Parameter Values" in the
User's Guide.
1. To print the job with the requested paper source:
a. Turn off the printer.
b. Install the desired forms device.
c. Turn on the printer.
d. Resubmit the print job.
2. To cancel the job now and resubmit the job later with the correct
device installed:
a. Press STOP.
b. Press CANCEL PRINT.
3. To print the job with an available paper source:
a. Press STOP.
b. Press PARK/PATH.
c. Select an available forms path.
d. Press START.
4. To print the job with the current paper source:
a. Press STOP.
b. Press START.
1. Press STOP to silence the alarm. The message remains in the
display.
2. Clear the jammed or torn form. If paper is difficult to remove from
the printhead area, note the setting on the AFTA wheel, rotate the
AFTA wheel to a higher number to clear the jam, and return the
AFTA wheel to the original setting.
3. Reload forms onto the tractor.
4. Close the top cover.
5. Press LOAD/EJECT to load forms.
6. Press START to restart the job.
7. If the message displays again, perform the actions under "Forms
buckle, twist, jam, or tear."
1. Press START.
All data will print in hexadecimal code until you press STOP.
