Right View

On the right side panel, you will find the followings:

Right-Side Stand

Slide this stand outward (together with the left-side stand) to adjust the
viewing angle.

Microphone-in Jack

This audio port accepts sound source to record or to playback when
externally connected microphone is used instead of the built-in one.

Line-in Jack

This audio port accepts sound source to record or to playback when the
sound source comes from other device's audio output than the systems.

Headphone Jack

This audio port accepts sound source to playback if externally connected
headphone is desired instead of the built-in speakers.

Infrared

The wireless communications capabilities are based on IrDA (Infrared
Data Association) standards for cordless connection between the
Notebook Computer and an IrDA-compliant device.

PC Card Type III Expansion Slot

The Type III PC Card slot is located inside a flip-down panel. It allows you
to conveniently attach numerous accessories to the Notebook Computer.
It is equivalent to two Type II PC Cards slots. The ejection button for the
upper slot is located on the left. The ejection button for the lower slot is on
the right.

CD-ROM Drive

The 5.25" IDE CD-ROM drive uses the tray loading mechanism for ease
of use. Press the ejection button to load the tray from the drive unit.

Ventilation

The Notebook features ventilation to dissipate the system's operating
heat. Do not block or obstruct it during operation.
