Circular Addressing Mode

3.8.2.1 LD and ST Instructions
Example 3−4. LDW Instruction in Circular Mode
LDW .D1 *++A4[9],A1
Before LDW
A4
0000 0100h
A1 XXXX XXXXh
mem 104h 1234 5678h
Note: 9h words is 24h bytes. 24h bytes is 4 bytes beyond the 32-byte (20h) boundary 100h−11Fh; thus, it is wrapped around to
(124h − 20h = 104h).
SPRU733
The BK0 and BK1 fields in AMR specify the block sizes for circular addressing,
see section 2.7.3.
As with linear address arithmetic, offsetR/cst is shifted left by 3, 2, 1, or 0
according to the data size, and is then added to or subtracted from baseR to
produce the final address. Circular addressing modifies this slightly by only
allowing bits N through 0 of the result to be updated, leaving bits 31 through
N + 1 unchanged after address arithmetic. The resulting address is bounded
(N + 1)
to 2 range, regardless of the size of the offsetR/cst.
The circular buffer size in AMR is not scaled; for example, a block-size of 8 is
8 bytes, not 8 times the data size (byte, halfword, word). So, to perform circular
addressing on an array of 8 words, a size of 32 should be specified, or N = 4.
Example 3−4 shows an LDW performed with register A4 in circular mode and
BK0 = 4, so the buffer size is 32 bytes, 16 halfwords, or 8 words. The value in
AMR for this example is 0004 0001h.
mem 104h
1 cycle after LDW
A4 0000 0104h
A1 XXXX XXXXh
1234 5678h
Addressing Modes
5 cycles after LDW
A4 0000 0104h
A1 1234 5678h
mem 104h 1234 5678h
Instruction Set 3-31
