Texas Instruments TMS320C67X Reference Manual page 105

Opcode
31 29 28 27
creg z dst
3 1 5
Description for .L1, .L2 and .S1, .S2 Opcodes
Execution for .L1, .L2 and .S1, .S2 Opcodes
SPRU733
.S unit
23 22 18
src2
5
Opcode map field used... For operand type...
src1
src2
dst
src1
src2
dst
src2 is added to src1. The result is placed in dst.
if (cond)
src1 + src2
→
else nop
Add Two Signed Integers Without Saturation
17 13 12 11
src1 x
5 1
sint
xsint
sint
scst5
xsint
sint
dst
6 5 4 3
op 1 0 0 0 s p
6
Unit Opfield
.S1, .S2 00 0111
.S1, .S2 00 0110
Instruction Set
ADD
2 1 0
1 1
3-45
