Instruction Type
Delay Slots
See Also
Example 1
Example 2
SPRU733
Single-cycle
0
EXT
EXTU .S1 A1,10,19,A2
Before instruction
A1 07A4 3F2Ah
A2 xxxx xxxxh
EXTU .S1 A1,A2,A3
Before instruction
A1 03B6 E7D5h
A2 0000 0156h
A3 xxxx xxxxh
Extract and Zero-Extend a Bit Field
1 cycle after instruction
A1 07A4 3F2Ah
A2 0000 121Fh
1 cycle after instruction
A1 03B6 E7D5h
A2 0000 0156h
A3 0000 036Eh
Instruction Set
EXTU
3-115
