Ofx (Offset X Direction); Ofy (Offset Y Direction); Sample Header - Microcom 424 Operator's Manual

Designing Labels Using LDS
SBL (25) =
DRM (203) =
The SPG can be fine adjusted by temporarily adding a line at dot row #1 using Line Draw
and adjusting the SPG number up and down to get desirable registration.
4.4.10 OFX (Offset X Direction)
HFM, LSX, LSY, WEB, GAP, DPS, LCB, AGD, SPG,
This parameter is used to move or offset all format fields in the X direction without altering
the format fields coordinates themselves.
4.4.11 OFY (Offset Y Direction)
HFM, LSX, LSY, WEB, GAP, DPS, LCB, AGD, SPG, OFX,
This parameter is used to move or offset all format fields in the Y direction without altering
the format fields coordinates themselves.

4.5 Sample Header

This is the header for the format used to generate the printed sample in Figure 4-2 followed
by a summary of the header values.
5, 1280, 900, 20, 40, 7, 0, 1, 405, 0, 0 <CR>
5 =
1280 =
900 =
20 =
40 =
7 =
0 =
1 =
405 =
0 =
0 =
<CR> =
4.6 Label Format Fields
The Label Format Fields are used to define the characteristics, placement and
representation of the corresponding text data of the individual fields. A format field is
broken down into many different parameters. It is not necessary to enter values for all of the
parameters (default value will be used if a parameter is left blank) but each parameter must
be separated with the comma delimiter (","). A carriage return must follow each format field
for proper operation to occur. The values entered must be positive integers for all of the
parameters of the format field.
4-10
The Space Between Labels, or die-cut GAP in this case;
.125" x 203 DPI = 25 dots.
The Distance to Registration Mark is from the leading edge of
the printable area to the next registration mark;
1" x 203 DPI = 203 dots.
5 format fields are following the header.
LSX (total print head dots) is 1280 dots.
LSY (label height) measures 3" or 900 dots.
WEB measures 0.0625" or 20 dots.
GAP measures 0.123" or 40 dots.
Print speed (DPS) of 7 = 4.5 inches per second.
LCB of 0 for die-cut labels.
AGD of 1 step.
SPG of 405 for proper placement of the next label.
No X offset.
No Y offset.
A carriage return must follow the header.
OFX
, OFY
OFY
