Designing Labels Using LDS
4.4.10 OFX (Offset X Direction)
HFM, LSX, LSY, WEB, GAP, DPS, LCB, AGD, SPG,
This parameter is used to move or offset all format fields in the X direction without altering
the format fields coordinates themselves.
4.4.11 OFY (Offset Y Direction)
HFM, LSX, LSY, WEB, GAP, DPS, LCB, AGD, SPG, OFX,
This parameter is used to move or offset all format fields in the Y direction without altering
the format fields coordinates themselves.

4.5 Sample Header

This is the header for the format used to generate the printed sample in Figure 4-2 followed
by a summary of the header values.
5, 1280, 900,19 ,38 ,7 ,0 ,1 ,385, 0, 0 <CR>
5 =
1280 =
900 =
19 =
38 =
7 =
0 =
1 =
385 =
0 =
0 =
<CR> =
4-10
5 format fields are following the header.
LSX (total print head dots) is 1280 dots.
LSY (label height) measures 3" or 900 dots.
WEB measures 0.0625" or 19 dots.
GAP measures 0.125" or 38 dots.
Print speed (DPS) of 7 = 4.5 inches per second.
LCB of 0 for die-cut labels.
AGD of 1 step.
SPG of 385 for proper placement of the next label.
No X offset.
No Y offset.
A carriage return must follow the header.
OFX
, OFY
OFY
