Printer Commands
3 Type of Top Of Form Sensor: The leading edge of the label stock can
be sensed using either a reflective sensor or a transmissive sensor.
4 Enable Power ON TOF: This bit controls whether or not the printer will
do an automatic Top Of Form (TOF) when it is turned ON.
5 Enable Button TOF: This bit determines whether the print button
functions as a Top Of Form or as a PRINT.
6 Enable Auto-Load: This bit determines whether the Auto-Load function
is ON or OFF.
7 Type of Auto-Load: This bit determines whether the Auto-Load
function uses the Top Of Form sensor (TOF), or if it uses the Form
Feed technique.
8 General Purpose Mode: If enabled, the printer will enter a special
mode of communications using the Ethernet port.
0 = Disable General Purpose Mode
5.2.2.6

Software Switch #6

^AB ^D COMMAND
XX 26 Change SW6: Software Switch #6.
^AB12345678 (each bit is represented by a numeric position number)
Position:
1 Enable Test Pattern or Halt on >TRAY FULL<: This bit is used to
define whether a test pattern will print, or if the printer will halt on a
>TRAY FULL< error when used with the optional catch tray. This bit
will determine the printer's response when pin 4 of P17 is active.
2 Always 0
3 Always 0
5-10
1 = TOF is TRANSMISSIVE
0 = TOF is REFLECTIVE
1 = Enable Power-ON TOF
0 = Disable
1 = Button is TOF
0 = Button is PRINT
1 = Auto-Load is ON
0 = Auto-Load is OFF
1 = Auto-Load is TOF
0 = Auto-Load is FF
1 = Enable General Purpose Mode
1 = >TRAY FULL< condition.
0 = A test pattern is printed.
224/424 Operator's Manual - 880027-1000
Chapter 5
