media that contains an LSY value greater than "285". For media that has a LSY value less
than "285", the SPG will need to be calculated.
If the label height is greater than or equal to 285 then the SPG = 285.
If the label height is less than 285, subtract (LSY+GAP) from 285 until the answer is
negative, then add (LSY+GAP) until the result is positive again. Subtract the AGD value
and the result will be the proper SPG value.
5.4.10 OFX (Offset X Direction)
This parameter is used to move or offset all format fields in the X direction without altering
the format fields coordinates themselves.
5.4.11 OFY (Offset Y Direction)
This parameter is used to move or offset all format fields in the Y direction without altering
the format fields coordinates themselves.
5.5

Sample Header

This is the header for the format used to generate the printed sample in Figure 8 followed by
a summary of the header values.
5, 575, 609, ,25 ,35 ,0 ,1 ,285, 0, 0 <CR>
5 =
575 =
609 =
, , =
25 =
35 =
0 =
1 =
285 =
0 =
0 =
<CR> =
322M Operator's Manual
5 format fields are following the header.
Label width (LSX) of 575 (575 / 203 = 2.83").
Label height (LSY) of 609 (609 / 203 = 3").
Default WEB value of 13 will be used.
GAP between labels of 25 (25 / 203 = .123").
Print speed (DPS) of 35 = 2 inches per second.
LCB of 0 for die-cut labels.
AGD of 1 step.
SPG of 285 for proper placement of the next label.
No X offset.
No Y offset.
A carriage return must follow the header.
