Bar Codes
Sample RSS-14 FORMAT: This sample uses the standard RSS-14 symbology
^D114<CR>
0<CR>
5<CR>
22<CR>
0<CR>
0<CR>
5<CR>
0012345612345
^D57<CR>
2,575,609,,25,35,0,1,285<CR>
1,190,300,1,46<CR>
2,190,200,11,1,5<CR>
^D56<CR>
^D2<CR>
x
^D3<CR>

8.2 Bar Code Rotation

When 0 and 180 degree bar codes are X multiplied (CMX), the space between characters is
also multiplied by the printer internally to maintain the correct ratio. When multiplying bar
codes use the default value for the spacing element (SP) in the field format parameters. On
some bar codes that allow spacing to be adjusted, spacing may be increased from the
default and not reduced to a smaller spacing.
When 0 and 180 degree bar codes are Y multiplied (CMY), the result is the actual height of
the bar code in thermal dots. If the Y multiplier (CMY) is not multiplied, a bar code with a
vertical length of one dot would be produced. For example: If a one inch high bar code is
desired using a 203dpi print head, 203 should be inserted for the CMY value.
When 90 and 270 degree, ladder or vertical, bar codes are X multiplied (CMX), the result is
the actual width of the bar code in thermal dots. If the X multiplier (CMX) is not multiplied, a
bar code with a horizontal length of one dot would be produced. For example: If a one inch
wide bar code is desired using a 203 dpi print head, 203 should be inserted for the CMX
value.
° °
When 90 and 270 degree bar codes are Y multiplied (CMY), the space between
characters is also multiplied by the printer internally to maintain the correct ratio. When
multiplying bar codes use the default value for the spacing element (SP) in the field format
parameters. On some bar codes that allow spacing to be adjusted, spacing may be
increased from the default and not reduced to a smaller spacing.
8-20
Here comes RSS-14 data
Use standard RSS-14 symbol
Multiply size by 5
Use 22 segments/row
X undercut = 0
Y undercut = 0
Set vertical separator = 5
13 digits of data
START of Label FORMAT
END of Label FORMAT
START of Text String
any character will do... this is just a placeholder
PRINT command
Figure 8-10 RSS-14 Sample Label FORMAT
TCI=35 calls for a RSS-14 barcode
224/424 Operator's Manual - 880027-1000
Chapter 8
