Printer Commands
^A ^D COMMAND
113 Verbose Mode:
0 Disable Verbose Mode
1 Enable Verbose Mode
X 145 List Commands.
This command is used to generate a list of commands containing a brief
description of the LDSI code base that the printer uses.
0 Show all commands.
1 Show current volatile settings.
2 Show current soft switch settings in plain English.
X 152 48-466 SPG Correction.
This command is nonvolatile and only used in conjunction with the 48-466
Emulation mode (^D26 command). It is used to adjust the SPG value to
compensate for the mechanical differences between the 48-466 and X24
printers. Each time the printer receives an SPG value; it will be decreased or
increased by the amount entered for ^Axx. If the XX value is less than 127
then; SPG = SPG - XX. If the XX value is greater than 127 then; SPG = SPG
+ XX - 127.
Example: If the value for XX was 33 and a format is sent to the printer with the
SPG set to 100, the resulting SPG would be 67 (SPG = 100 - 33).
Example: If the value for XX was 147 and a format is sent to the printer with
the SPG set to 90, the resulting SPG would be 110 (SPG = 90 + 147 - 127).
Send a ^A1^D145 command to the printer to view the correction factor setting
and the calculated SPG value that the printer will use for registration.
X 153 Dot Feed Forward.
Feeds the media forward at the given speed. The ^Ax is the number of dots to
move.
X 154 Dot Feed Reverse.
Feeds the media in reverse at the given speed. The ^Ax is the number of dots
to move.
X 155 Dot Feed Speed.
Controls the feed speed of the ^D153 and ^D154 commands. The ^Ax is the
DPS value 0 through 13.
