Windows XP Information
8 Channel Sound Support
If you wish to configure your system for 8 channel sound support, then the following ports should be used as
outputs. Connect the system cables to the following audio jacks:
• Side Speaker Out - Connect to S/PDIF Out
• Center/Subwoofer Speaker Out - Connect to Microphone In
• Front Speaker Out - Connect to Speaker/Headphone Out
• Rear Speaker Out - Connect to Line In
D
D - 10 Audio Features
Figure D - 7
- 8 Channel Sound Support
8 Channel Sound Support
Double-click the Realtek HD Audio Manager
icon in the taskbar to bring up the Realtek
control panel.
Click Audio I/O (tab).
Select 8CH Speaker from the pull-down menu.
Click OK to save.
Connect the cables to the audio jacks as out-
lined.
