Quick Start Guide
1

LED Indicators

The LED indicators on the top case, and at the front of the computer, display helpful information about the cur-
rent status of the system.
Icon Color
Green
Green
Green
Green
Airplane Mode is ON (the WLAN, Bluetooth
Green
Table 1 - 1 - LED Indicators
1 - 8 LCD Panel Open - Model B
Top Case LEDS
Description
Number Lock is Activated
Caps Lock is Activated
Scroll Lock is Activated
Hard Disk Activity
& 3G/4G Modules are OFF)
Front Case LEDS
Icon Color
Orange
The Battery has Reached Critically Low
Blinking Orange
Green
Orange
Blinking Orange*
Green
Blinking Green
Description
The Battery is Charging
Power Status
The Battery is Fully Charged
AC/DC Power is Plugged In
The Powered USB Port is On
(see "Powered USB 3.0 Port (including
eSATA Port)" on page 1 - 22)
The Computer is On
The Computer is in Sleep Mode
