Quick Start Guide
1

System Map: Bottom View

Figure 1 - 7 - Bottom View
1. Vent/Fan Intake/Outlet
2. Battery
3. Optical (CD/DVD) Device Drive Release
Cover
4. Component Bay Cover
5. Hard Disk Drive Bay Cover
6. Speaker
The CPU is not a user serviceable part. Open-
ing this compartment, or accessing the CPU in
any way, may violate your warranty.
To prevent your computer from overheating
make sure nothing blocks the vent(s)/fan in-
take(s)/outlet(s) while the computer is in use.
1 - 12 System Map: Bottom View
CPU
Overheating
2
3
1 1
5
6
4
