System 5 Frame Set, 6Ft: Part# 946-06425-01 - Euphonix System 5 Control Surface/Frame Manual

Parts List (cont)
S5 Control Surface/Frame Manual

System 5 Frame Set, 6ft: Part# 946-06425-01

Item#
726-06399-01
726-06400-01
726-06408-01
726-06402-01
726-06403-01
726-06404-01
726-06411-01
726-06686-01
600-07223-00
032-07147-00
032-07148-00
032-07149-00
032-07150-00
081-07193-00
936-07218-01
043-06688-00
082-06689-00
046-06401-00
046-06421-00
081-07193-00
936-07241-01
044-07236-00
936-07239-01
000-06690-00
044-06686-00
936-07240-01
040-06833-00
030-07394-01
Item Description
Beam-Box 6ft S5
Clamp-Beam
Beam-Back 6ft S5
Plate-Back Beam
Palm Rest-6ft S5
Plate-Palm Beam
Brace-Back
Cover-Back 3ft
Power Strip-Iec320-6pos
Iec320 Jumper Cordset-0.5m
Iec320 Jumper Cordset-1.0m
Iec320 Jumper Cordset-1.5m
Iec320 Jumper Cordset-2.5m
3/8 Flat/Wash/Ss
S5 Frame Bolt Kit
5/16-18x3.5 Bolt Hex-Head-Zi
5/16 Lockwasher
5/16-18x2.25 Bolt Flat/Soc/Ss
3/8-16x1.25l Buttonhd/Skt/Ss
3/8 Flat/Wash/Ss
S5 Rear Panel Bolt Kit
¼-20x3/8 B4cs
S5 Tee Hardware Kit
5/16-18x.375 Tee Nut/Cz
5/16-18x.375 Bolt Socket Hd/Cz
S5 Thumb Screw Kit
10-32x3/8 Thumb\Washer Face
Ca-Internal Ethernet/6ft
Page 48
Qty
2
4
1
2
1
2
1
2
2
5
3
2
1
8
1
16
16
8
8
8
1
20
1
22
22
7
4
1
Version 1.0 ©1999 Euphonix, Inc.
