All Switch LEDs Toggle

This switch toggles all the upper board LEDs on and off. This mode times out after
5 mins if all LEDs are left ON and goes into Vegas mode.

Color Toggle

This switch cycles between the same color LEDs in the following order
• Green
• Red
• Yellow
• Orange
• Blue

All Switch and Indicator LEDs Toggle

This toggles all the upper and lower board LEDs including the daughter board
LEDs.
NOTE: For thermal reasons, the module should not be left with all LEDs On. Use
Vegas mode for burn-in. For protection, the module will time out into Vegas mode if
all LEDs are left ON for more than 5 minutes.

Vegas Mode

Flashes alternate LEDs on and off. The default Vegas mode also puts the fader into
cycle test. Repeated presses of this key toggles the fader cycle on/off. If left
running, the fader cycle will time out after 5 minutes.
