All fader up

All faders all the way up

All fader down

All faders all the way down

Fader cycle test with speed control

All faders cycle up and down at the speed determined by the speed control knob.
The speed control knob also varies the brightness of the TFT backlight when in this
test. It should vary from all the way off to the brightest setting. This fader cycle
test times out after 5 minutes to protect the faders from burn-out.

Fader echo test

All faders follow the one fader touched.

Touch Sense Test

Self-test touch sense LED lights up when a fader is touched. This mode is always
active in fader test mode.

Backstop PFL switch test

Self test backstop PFL LED lights up when a fader is pulled back to enable its
backstop PFL switch. This mode is always active in fader test mode.

Fader Write value display

Any value written to a fader is displayed in its designated fader write intelligent
display. This mode is always active in fader test mode.

Fader Read value display

All faders are continuously read and the read value is displayed in its designated
fader read intelligent display. This mode is always active in fader test mode.

TFT backlight brightness test

See Fader cycle test.
