APPENDIX 1

Parts Lists

S5 Control Surface/Frame Manual
System 5 Leg Set
Item#
726-06398-01
726-06846-01
726-06394-01
726-06415-01
726-06493-01
041-06290-00
726-06791-01
000-06790-00
420-04065-00
600-06387-00
600-00728-00
110-05551-00
726-06419-01
726-06847-01
726-06826-01
042-05677-00
048-00929-00
046-06073-00
726-06405-01
06406-01
726-06407-01
726-06838-01
044-06686-00
081-06417-00
726-06832-01
000-06434-00
600-06991-00
030-06993-01
030-06994-01
030-06995-01
030-06996-01
030-06997-01
030-06998-01
030-06999-01
006-04969-00
049-00838-00
032-07207-00
030-07199-01
: Part# 946-07220-01
Item Description
Leg-Left-Finished S5
Leg-Left-Machined S5
Panel-Weldment-Left Leg
Keyboard Tray Assy
Track-Keyboard Top S5
10x32x1/4 Pan/Phil/Cz
Track-Keyboard Base S5
Glide-Keyboard S5
Dpdt-20a Rocker
Iec320/C14 Power Entry
Line Filter/Am
Coupler Rj45 Panel Mount
Leg-Right-Finished S5
Leg-Right-Machined S5
Panel-Weldment-Right
6-32x3/16 Flat/Phil/Clrznc
6-32x3/8 Pan/Phil/Sem-Ext/Clr
4-40x1/4l Pan/Phl/Clr Zinc
Bracket-Rear Caster
Bracket-Front Caster
Caster-36mm
Spacer-Left-S5 Cm
5/16-18x.375 Bolt Socket
#10 Flat Washer-Brass
Ac Cover S5
Leveling Pad-5/16-18
Iec320/C13 Power Outlet
Ca-Ac Line-S5 Frame
Ca-Ac Neutral-S5 Frame
Ca-Ac Gnd-S5 Frame
Ca-Outlet Ac Line-S5 Frame
Ca-Outlet Ac Neutral-S5
Ca-Sw Line-S5 Frame
Ca-Sw Neutral-S5 Frame
Label-Universal Ground
6-32 Kepnut/Ext/Clr Zinc
Ca-Pwr/Iec/N-Usa/8ft/15a
Ca-Door Support-S5
Page 46
Qty
1
1
1
1
1
8
1
2
1
1
1
12
1
1
1
14
4
4
2
2
4
1
8
2
2
4
3
1
1
5
1
1
1
1
1
12
1
4
Version 1.0 ©1999 Euphonix, Inc.
