CONTROL MODULES SECTION

Physical Specifications

Top View - Control Modules

5"
12"
41"
3
Frames are available in 6ft, 9ft, and 12ft sizes. Actual width of Control Surface is
frame size + 10 inches.
Item No.
A
B
C
D
1
3
*
Qty depends on specified configuration
S5 Control Surface/Frame Manual
A
Qty Description
* CM408 Control Module
* CM402 Control Module
1 CM401 Control Module
* TFT Display
1 Leg, right
1 Leg, left
6'10"
B C
Page 21 Version 1.0 ©1999 Euphonix, Inc.
D
A 1
Part No.
946-05717-01
946-05719-01
946-05718-01
Inc. in CM Module
726-06419-01
726-06398-01
