Dimensions and Weight

Approximately 14 inches of depth should be left behind the System 5 Control
Surface for cable connections.

Technical Specifications

Environmental Requirements

Environmental requirements for the System 5 Control Modules are as follows:
Operating Temperature:
Storage Temperature:
Humidity:

Power Requirements

90 to 254 Volts AC (rms), 50/60Hz, 150 Watts per module.

Power Consumption

Power consumption of the Control Surface Modules is shown in the table below.
Module
CM401
CM402
CM408
• Inrush current : 25 Amps
• Fuse Rating:
S5 Control Surface/Frame Manual
Module
CM401:
CM402:
CM408:
CM409F:
CM409H:
CM409HTP:
Individual Module Power Consumption
US (117V)
1.0A
1.0A
1.0A
5Amp Slo-Blo or Time Delay
Weight
35lbs (16kg)
35lbs (16kg)
35lbs (16kg)
16lbs (7kg)
9lbs (4kg)
10lbs (4.5kg)
0 to 40 degrees Celsius (ambient)
-10 to 55 degrees Celsius
0 to 90% non-condensing
Europe (230V)
.5A
.5A
.5A
Page 23
Width
12"
12"
12"
12"
6"
6"
Japan (100V)
1.0A
1.0A
1.0A
Version 1.0 ©1999 Euphonix, Inc.
