14) Using a ¼" hex driver and 5/16x18x0.375 socket head screws (044-06686-00), install
the back cover braces (item 15, brace 1). Determine the position of the braces by
aligning them with the back cover mounting screw holes. Move the slide nuts in the
rear box beam and back beam to the brace locations, and mount the braces to them.
S5 Control Surface/Frame Manual
Page 15
Version 1.0 ©1999 Euphonix, Inc.
