Cabinet-Mounted Speaker Connector
The 2-pin speaker cable connects to the speaker connector on the system board.
ATX System Board Power Supply Connector
The 20-pin ATX power supply cable connects to the ATX power supply connector on the
system board. The plug from the power supply only connects one way.
Speaker Connector
ATX Power Supply Connector
