Intergraph TD-260 System Manual page 73

DIP Switches
Key Name
1 CONFIG (J11)
2 IOD (J26)
3 PWLC (J36)
Expansion Slots
Key Name
4 DIMM sockets
5 ISA slots
6 PCI slots
7 AGP slot
Connectors and Ports
Key Name
8 PS/2 keyboard
9 PS/2 mouse
10 USB
11 Printer
12 COM 1, COM 2
13 IDE 1
14 IDE 2
15 FDD
16 POWER (J27)
17 CPU_FAN (J13)
18 PSU_FAN (J20)
19 F_Panel (J30)
20 SPK (J24)
21 PC/PCI (J34)
22 WOM (J33)
23 WOL (J35)
24 SYS_FAN (J28)
25 CHAS_IN (J39)
Switch
Processor core frequency header setting (2-pin)
Depth of In-Order Queue setting (2-pin)
Power loss condition selection (3-pin)
Slot
168-pin, 64-bit DIMM sockets
98-pin, 16-bit ISA bus expansion slots
120-pin, 32-bit PCI bus expansion slots
124-pin, 32-bit AGP bus expansion slot
Connector
PS/2 keyboard (6-pin female)
PS/2 mouse (6-pin female)
Universal Serial Bus (two 4-pin female)
LPT parallel port (25-pin female)
COM 1, COM 2 serial ports (two 9-pin male)
Primary IDE (40-pin)
Secondary IDE (40-pin)
Floppy disk drive (34-pin)
System board ATX power supply (20-pin)
Processor cooling fan (3-pin)
Power supply fan (3-pin)
Front panel connector for mini-tower (16-pin)
Speaker output (2-pin)
DMA connector for PCI audio card (6-pin)
Modem add-on card wake-up (3-pin)
LAN add-on card wake-up (3-pin)
Reserved for system fan connector (3-pin)
Reserved for chassis intrusion connector (2-pin)
59
