Intergraph TD-260 System Manual page 61

The following are common memory configurations:
Memory
16 MB
32 MB
48 MB
64 MB
96 MB
128 MB
192 MB
256 MB
320 MB
384 MB
To replace system memory:
1. Ensure the pins on the DIMMs match the socket keying.
2. Align pin 1 on the memory module with pin 1 of the socket.
3. Insert the DIMM into the socket at a 90-degree angle. Use even pressure across the top of
the module; then push the module upright until it locks in place.
CAUTION Do not use a rocking motion as you install the memory module. Doing so might damage the
module, the socket, or both.
For more information on system memory, see Chapter 8, "System Board Overview," and
Chapter 9, "System Board Upgrades."
Bank 0 Bank 1
DIMMs DIMMs
One 16 MB
One 16 MB One 16 MB
One 32 MB
One 16 MB One 16 MB
One 64 MB
One 32 MB One 32 MB
One 32 MB One 32 MB
One 128 MB
One 64 MB One 64 MB
One 64 MB One 64 MB
One 128 MB One 128 MB
One 128 MB One 128 MB
One 128 MB One 128 MB
Bank 2
DIMMs
One 16 MB
One 32 MB
One 64 MB
One 64 MB
One 128 MB
47
