8

FRU monitoring

•
•
The policy you defined determines the output in the Switch Status Policy Report.
See

FRU monitoring

Supported FRU areas depend on the type of Brocade switch. For the following switches, the slot
and WWN areas are not supported:
•
•
•

FRU class areas

Table 29
FRU-class areas are absent or removed, faulty, inserted, on, off, ready, and up. Configure the FRU
class using the fwFruCfg command
TABLE 29
Area
Fan
Power supply
Slot
WWN
SFP

Configuring FRUs

The configuration of field-replaceable units (FRUs) is an exception to the procedures described
thus far in this chapter. FRUs are monitored using state values, as opposed to the quantitative
values used to monitor the rest of the fabric. As a result of the qualitative nature of this monitoring,
the concept of thresholds does not apply.
NOTE
The Off state is applicable only to fans on some platforms, such as the Brocade DCX and Brocade
DCX-4S. The Off state is not applicable to the power supply, slot, or WWN FRUs.
1. Establish a Telnet connection with a switch.
2. Log in using administrative privileges.
3. Enter the fwFruCfg command at the command prompt.
84
Missing SFPs—Monitors the number of ports without SFPs.
Error Ports—Ports that are disabled because of segmentation, an authentication failure, port
fencing, or bottleneck detection.
Chapter 10, "Fabric Watch Reports,"
Brocade 300, 5100, and 5300 switches
Brocade DCX and DCX-4S Data Center Backbone
Brocade Encryption Switch
lists Fabric Watch areas in the FRU class and describes each area. Possible states for all
FRU class areas
Description
State of a fan has changed.
State of a power supply has changed.
State of a slot has changed.
State of a WWN card has changed.
State of the SFP has changed.
The fwFruCfg command displays your current FRU configuration. The types of FRUs are
different for the various platforms.
for more details about the Switch Status Policy Report.
53-1002752-01
Fabric Watch Administrator's Guide
