Detailed Information
Item
Port
Fibre Addr.
Num. of Ports

[PROV] Set Fibre Topology

This log is output when LUN Manager operation is performed using Configuration File Loader.
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[PROV],Set Fibre Topology,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,Fabric,Connection}
=[{XX,Enable,FC-AL},{XX,Disable,FC-AL},
{XX,Enable,P-to-P},{XX,Disable,P-to-P}],Num. of Ports=4
Detailed Information
Item
Port
Fabric
Connection
Num. of Ports

[PROV] Set Host Mode

This log is output when LUN Manager operation is performed using Configuration File Loader.
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[PROV],Set Host Mode,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,HostGrpID,Mode,Option[0:31],Option[32:63],Option[64:95]}
=[{XX,0xXXX,0x00,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX},{XX,0xXXX,
0x4F,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX}],Num. of Host Groups=2
Detailed Information
Item
Port
HostGrpID
Mode
Description
The name of the port that the fibre address has been set.
It displays the address of Fibre Channel port after the setting.
The outside of parenthesis indicates AL-PA and the inside of parenthesis indicates the loop ID.
The number of ports where address has been set.
Description
The name of the port where the topology of Fibre Channel is set.
Indicates whether the Fabric switch is enabled or disabled.
Enable: Enabled, Disable: Disabled
The connecting mode of the Fabric switch selected.
FC-AL: FC-AL is selected, P-to-P: P-to-P is selected
The number of ports where the topology of Fibre Channel is set.
Description
The name of the port where the host group is created.
The host group number.
The host mode set. Please see the HP StorageWorks P9000 Provisioning for Open Systems User
Guide for the meaning of the host mode number.
Provisioning Descriptions 129
