RCU Descriptions

[RCU] Add Path

Example 1: CU Free is used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Add Path,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID}
={99999,0x00,0x00,Default,4}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},
{5G,7G},{1H,3H}],Num. of Port Pairs=7
Example 2: CU Free is not used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Add Path,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,MCU,RCU LDKC,RCU,SSID,Controller ID}
={99999,0x00,0x3F,0x00,0x7F,0x0004,4}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},
{5G,7G},{1H,3H},{5H,7H}],Num. of Port Pairs=8
Detailed Information
Item
S/N
MCU LDKC
RCU LDKC
Path Gr.ID
Controller ID
MCU
RCU
SSID
MCU Port
RCU Port
Num. of Port Pairs

[RCU] Add RCU

Example 1: CU Free is used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Add RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID,Min.Path,
MIH Time(s),Round Trip Time(ms),FREEZE}
={99999,0x00,0x00,Default,4,08,015,001,Disable}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},
{5H,7H}],Num. of Port Pairs=8
Description
Indicates a serial number of the device.
The LDKC number of the connected LDKC.
The LDKC number of the paired LDKC.
The path group ID. When the path group ID is default setting, "Default" is output.
The controller ID.
The CU number of the connected CU.
The CU number of the paired CU.
The SSID.
The port number of MCU.
The port number of RCU.
The number of port pairs set.
