Detailed Information for Example 6
Item
MPB
Auto LDEV Assignment
Num. of MPBs
Example 7: installing additional SVP
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,SVP,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{SVP}={SVP-OPTION}
+{IPAddress,Subnet Mask}
={(123.456.789.123),(255.255.255.255)}
+Use Duplex= Valid
+SVP Kind= Master SVP
+IPv4=Valid
+IPv6=Valid
+{M-SVP IPv4(IPAddress,Subnet Mask),IPv6(IPAddress,
Subnet Prefix length)}
={((111.222.333.444),(255.255.255.255)),
((1111:2222:3333:4444:5555:6666:7777:8888),(64))}
+{ S-SVP IPv4(IPAddress,Subnet Mask),IPv6(IPAddress,
Subnet Prefix length)}
={((555.666.777.888),(255.255.255.255)),
((9999:AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:0000),(64))}

Basic Information

Parameter Description
SVP Indicates a change in the IP adress of the SVP.
SVP&DKC Indicates a change in the IP adress of the SVP and the DKC.
Detailed Information for Example 7
Item
SVP
IPAddress
Subnet Mask
Use Duplex
SVP Kind
IPv4
IPv6
Description
The installed location of the MPB.
The attribute of auto LDEV assignment.
The number of MPBs.
Description
The installed location of the SVP.
IP address in the SVP.
The subnet mask in the SVP.
The duplex status of the SVP.
Valid or Invalid will appear.
The kind of the duplex status.
Master SVP or Stanby SVP will appear.
The status of IPv4 settings.
Valid or Invalid will appear.
The status of IPv6 settings.
Valid or Invalid will appear.
[Install] Cache Residency Prestaging 67
