Detailed Information for Example 5
Item
PCI ADP Equip
Example 6: removing additional MPB
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
{MPB,Auto LDEV Assignment}
=[{MPB-1MB,Enable},{MPB-2MD,Enable},{MPB-1MF,Enable},
{MPB-2MH,Enable}],Num. of MPBs=4
Detailed Information for Example 6
Item
MPB
Auto LDEV Assignment
Example 7: removing additional SVP
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,SVP,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{SVP}={SVP-OPTION}
+{IPAddress,Subnet Mask}={(123.456.789.123),(255.255.255.255)}
+Use Duplex=Invalid
+Svp Kind=Master SVP
+IPv4=Valid
+IPv6=Valid
+{M-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((111.222.333.444),(255.255.255.255)),
((1111:2222:3333:4444:5555:6666:7777:8888),(64))}
+{S-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((555.666.777.888),(255.255.255.255)),
((9999:AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:0000),(64))}
Basic Information
Parameter Description
SVP Indicates a change in the IP adress of the SVP.
SVP&DKC Indicates a change in the IP adress of the SVP and the DKC.
Detailed Information for Example 7
Item
SVP
IPAddress
Subnet Mask
Description
Whether the PCI is installed or not.
ON: Installed, OFF: Not installed
Description
The installed location of the MPB.
The attribute of auto LDEV assignment.
Description
The installed location of the SVP.
IP address in the SVP.
The subnet mask in the SVP.
