from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,Fabric,Connection}
=[{XX,Enable,FC-AL},{XX,Disable,FC-AL},
{XX,Enable,P-to-P},{XX,Disable,P-to-P}],Num. of Ports=4
Detailed Information
Item
Port
Fabric
Connection
Num. of Ports

[Install] Set Host Mode

Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set Host Mode,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,HostGrpID,Mode,Option[0:31],Option[32:63],Option[64:95]}
=[{XX,0xXXX,0x00,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX},
{XX,0xXXX,0x4F,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX}],
Num. of Host Groups=2
Detailed Information
Item
Port
HostGrpID
Mode
Option[0:31]
Option[32:63]
Option[64:95]
Num. of Host Groups

[Install] Set IP Address

Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set IP Address,SVP&DKC,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
Set IP Address,SVP&DKC,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx+{IPAddress,Subnet Mask}
={(123.456.789.123),(255.255.255.255)}+Use
Duplex=Valid+Svp Kind=Master SVP+IPv4=Valid+IPv6=Valid+{M-SVP
IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((111.222.333.444),(255.255.255.255)),
((1111:2222:3333:4444:5555:6666:7777:8888),(64))}+{S-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
Description
The name of the port where the topology of Fibre Channel is set.
Indicates whether the Fabric switch is enabled or disabled.
Enable: Enabled, Disable: Disabled
The connecting mode of the Fabric switch selected.
FC-AL: FC-AL is selected, P-to-P: P-to-P is selected
The number of ports where the topology of Fibre Channel is set.
Description
The name of the port where the host group is created.
The host group number.
The host mode set. Please see the HP StorageWorks P9000 Provisioning for Open Systems User
Guide for the meaning of the host mode number.
The specified host mode option. 96 host mode options from 0 to 95 are output in groups of 32
options. Please see Table 12 (page 111)
and host mode option.
Please see the HP StorageWorks P9000 Provisioning for Open Systems User Guide for the
meaning of the host mode number.
The number of host groups that the host mode setting is changed.
to Table 14 (page 113) for the relation of output values
