10
To replace the system disk drive:
1. Disconnect the power cable and SCSI cable from the disk drive.
2. Remove the four nuts (two on each side) from the vertical screws on each side of the disk
drive, and lift the disk drive out of the chassis.
3. Remove the brackets from the replaced disk drive and secure them to the new disk drive.
WARNING Handle the disk drive carefully to prevent failure and voiding the warranty for
the drive.
4. Replace the new disk drive in the chassis and secure it with the four nuts removed previously.
5. Connect the power cable and SCSI cable to the disk drive.
You will need to reinstall the operating system and associated system software on the new system
disk drive. See System Setup for more information.

CD-ROM Drive

To replace the CD-ROM drive:
1. For ease of access, remove the chassis fan as described later in "Chassis Fan."
Nuts (two on each side)
