Connectors

Connector
J10
J11
J14
J41
J42
J43
J44
J48
J51
J50
J55
J56
J57
J58
J61
J63
J64
J10 - Power Supply Fan Cable, 2-Wire
Pin Signal
1 Voltage +
2 Return -
J10 - Power Supply Fan Cable, 4-Wire
Pin Signal
1 Fan control input
2 Fan Tach 1
J11 - MCBLW680A, Serial Port 2
See "External Ports" in this chapter for serial port pinouts.
Cable Description
Not included Primary processor fan power
MCBLW68 Serial port 2 (COM2)
MCBL038 MIDI/game connector
MCBL387 Narrow Ultra SCSI
P1 System board power
P2 System board power
MCBL194 Floppy drive CDSK146
Not included Secondary processor fan power
MCBL248 Front panel power LED (green)
Not included Chassis fan
MCBL250 Front panel power button
CFAN120 Chassis fan, bottom front
MCBL249 Front panel power management LED (yellow)
MCBL247 Front panel disk activity LED (green)
MCBL520 Speaker
MCBL339 LVDS Wide Ultra2 SCSI Channel A
MCBL340 LVDS Wide Ultra2 SCSI Channel B
Pin Signal
3 Voltage +
4 Return -
