Fibre Channel User's Guide
Congratulations on purchasing Intergraph's state-of-the-art Fibre Channel storage solution. If
you are a manager, you will find this solution gives you matchless performance in a cost-
competitive storage device. If you are a technician, you will find this solution easy to install,
reliable, and easy to maintain. If you are a user, you will enjoy fast access to a vast expanse of
storage space.
Using This Document
The Fibre Channel User's Guide contains all the information you need to install and use your
Fibre Channel disk array. This document is organized as follows:
u
SS-1200 FCAL Rack Installation and User Guide describes how to install, configure, and
connect the Fibre Channel enclosure to your system, and how to use and maintain it.
u
SS-1200 FCAL LRC Input/Output Module Installation Guide describes how to install the
Fibre Channel Arbitrated Loop (FCAL) Loop Resiliency Circuit (LRC) input/output (I/O)
modules in the Fibre Channel enclosure.
u
SS-1200 FCAL Drive Carrier Module Installation Guide describes how to install the FCAL
drive carrier modules in the Fibre Channel enclosure.

Before You Begin

CAUTION
To protect the Fibre Channel enclosure and related equipment from electrostatic
discharge, wear an anti-static wrist strap when setting up or reconfiguring the
enclosure.
WARNING
To avoid damage to the enclosure's power supply, set the voltage range
switch on the power supply to the proper AC line voltage for your location
(115 V or 220 V) before you connect the power cord and turn on power to
the enclosure.

Customer Support

Intergraph Computer Systems offers an assortment of customer support options.
u
Intergraph Computer Systems provides a variety of hardware services for Intergraph and
third-party equipment. Services include warranty upgrades, repair depot service, on-site
hardware maintenance, system administration, and network consulting. Hardware purchased
from Intergraph Computer Systems includes a factory warranty ranging from 30 days to three
years. A detailed warranty description is available on the World Wide Web; see the Support
pages at http://www.intergraph.com/ics.
u
Intergraph Computer Systems provides complimentary software support for 30 or 90 days
following shipment of a hardware or software product. This includes World Wide Web
access, Intergraph Bulletin Board Service access, FAXLink service, and telephone (Help
Desk) support. At the end of the complimentary support period, you can purchase other
levels of software support.
DHAV04500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fibre Channel and is the answer not in the manual?

Questions and answers

Related Manuals for Intergraph Fibre Channel

Summary of Contents for Intergraph Fibre Channel

  • Page 1: Before You Begin

    Using This Document The Fibre Channel User’s Guide contains all the information you need to install and use your Fibre Channel disk array. This document is organized as follows: SS-1200 FCAL Rack Installation and User Guide describes how to install, configure, and connect the Fibre Channel enclosure to your system, and how to use and maintain it.
  • Page 2 On these pages, you can get news and product information, technical support information, software updates and fixes, and more. On the Intergraph Bulletin Board Service (IBBS), you can get technical support information, software updates and fixes, and more. Using a modem (eight data bits, no parity, one stop bit, any baud rate up to 14,400), call 1-256-730-8786.
  • Page 3 SS-1200-FCAL Rack Installation and User Guide Part No. 19933-01 Issue 1.0 June 01, 1998...
  • Page 4 SS-1200-FCAL User Guide Notices The information in this document is subject to change without notice. While every effort has been made to ensure that all information in this document is accurate, the Authors accept no liability for any errors that may arise. No part of this document may be transmitted or copied in any form, or by any means, for any purpose, without the written permission of the Authors.

  • Page 5: International Standards

    Preface International Standards The Xyratex SS-1200 series storage system complies with the requirements of the following agencies and standards: • CE to IEC 950/EN60951 • UL • cUL Potential for Radio Frequency Interference USA Federal Communications Commission (FCC) Note This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules.

  • Page 6: Moving And Handling

    SS-1200-FCAL User Guide • A trifurcated power cord, as supplied with the SS-1200-FCAL system, must be used in order to safely provide a single power disconnect point. • If a power cord is not supplied with your SS-1200-FCAL system, a power cord suitable for the country of destination and for use with the SS-1200 system application should be provided.

  • Page 7: Data Security

    Preface Data Security • Power down your host computer and all attached peripheral devices before beginning installation. • Each enclosure contains up to 12 removable disk drive modules. Disk units are fragile. Handle them with care, and keep them away from strong magnetic fields. •...

  • Page 8: Preface

    Who should use this guide This user guide assumes that you have a working knowledge of the Fibre Channel Arbitrated Loop (FC-AL) environment into which you are installing the SS-1200-FCAL system. If you do not have these skills, or are not confident with the instructions in this guide, do not proceed with the installation.

  • Page 9: Table Of Contents

    Contents Contents International Standards ............................iii Potential for Radio Frequency Interference ......................iii European Regulations ............................. iii Safety ..................................iii Moving and Handling ............................. iv Data Security ................................v ESD Precautions ............................... v Year 2000 Compliance ............................. v Special Tools and Equipment ........................... v Preface ..................................
  • Page 10 SS-1200-FCAL User Guide 2.3.2 Rack Mounting Rail Kit ........................15 2.3.3 Chassis Installation ......................... 16 2.3.4 Power Supply/Cooling Module Installation ..................17 2.3.5 ESI/Ops Panel Module Installation ....................19 2.3.6 Other Plug-in Modules ........................22 2.3.7 Interface Cabling ..........................22 2.3.8 Blank Plates .............................

  • Page 11: Introduction

    Introduction Chapter 1 Introduction 1.1 The SS-1200-FCAL System Figure 1–1 The SS-1200-FCAL System 1.2 The Enclosure Core Product The SS-1200-FCAL design concept is based on a subsystem together with a set of plug-in modules. The Salient SS- 1200-FCAL subsystem as supplied comprises: •...

  • Page 12: Enclosure Chassis

    SS-1200-FCAL User Guide • An Enclosure System Interface/Operators Panel (ESI/Ops) plug-in module (see Figure 1–5). • Blank plates, as required to complete your required configuration and installation. • FC-AL Drive Carrier Modules and associated front dummy fascia plates. (See Figure 1–10).

  • Page 13: Tower Option

    Introduction 1.2.2 Tower Option An optional tower kit is available, which can be fitted to the rack chassis described here. Separate documentation is provided with this option. 1.3 The Plug-in Modules An SS-1200-FCAL Enclosure requires one or more of the following modules for normal operation: 1.3.1 Power Supply/Cooling Module Two Power Supply/Cooling modules are supplied mounted in the rear of the enclosure as part of the subsystem core...

  • Page 14: Enclosure System Interface/Operators Panel Module

    SS-1200-FCAL User Guide 1.3.2 Enclosure System Interface/Operators Panel Module Supplied as part of the Enclosure core product, a typical Enclosure System Interface/Operators (ESI/Ops) panel module is shown in Figure 1–5. Figure 1–5 ESI/Ops Panel Module The(ESI/Ops) Panel provides the enclosure with a micro controller which is used to monitor and control all elements of the Enclosure.
  • Page 15 Introduction ESI/Ops Panel Figure 1–7 ESI/Ops Panel (Rear mounting) Important Because the physical dimensions of the rear or front facing variants are different and they are not interchangeable, they must each be ordered under their own unique part number. 1.3.2.1 Ops Panel Indicators and Switches The Operator Panel includes Light Emitting diodes (LEDs) which show the status for all modules and an Audible Alarm which indicates when a fault state is present.
  • Page 16 SS-1200-FCAL User Guide System Drive Power/Cooling Standby Securing Latch Alarm Mute Run/Service Figure 1–8 Ops Panel Indicators and Switches 1.3.2.2 Manual Spin up Jumper A manual spin-up jumper can be fitted to the rear panel of the ESI/Ops module, it is used to disable the auto spin start function.

  • Page 17: Drive Carrier Modules

    Introduction 1.3.3 Drive Carrier Modules Please refer to separate installation guide for device specific information. Figure 1–10 Drive Carrier Module 1.3.4 Loop Resiliency Circuit Input/Output Module (FC) Please refer to separate installation guide for details. (SS-1200-FCAL LRC I/O Module Installation Guide). The FC-AL Backplane incorporates two independent loops formed by Port Bypass Circuits within the Loop Resiliency Circuit (LRC) I/O modules.

  • Page 18: Blank Plates

    SS-1200-FCAL User Guide 1.3.5 Blank Plates Blank plates must be fitted over all vacant bays at the rear of the enclosure as shown in Figure 1–12. There are three sizes of blank plate available: – Single bay Rear blank plates –...

  • Page 19: Anti-Tamper Locks

    Introduction 1.3.8 Anti-tamper Locks Anti-tamper locks may be fitted in the drive carrier handles (Figure 1–13) and are accessed through the hole in the lower part of the handle trim piece.These are provided to disable the normal “Push/Push” latch action of the handle. To lock turn 90º...

  • Page 20: Power Cord

    SS-1200-FCAL User Guide Power consumption (Normal 800 VA operation 12 x 9GB Drives) Power supply peak & operational 6.5 A Nominal @ 110V 10.5 A Peak @ 110V currents (per supply) Inrush Current 40/80 A @ 110/220VAC (25° cold start 1 PSU) 1.4.4 Power Cord (minimum requirements)

  • Page 21: Interfaces

    Introduction 1.4.6 Interfaces Drive support See drive carrier specification Attachment Dual 12 drive FC-AL Loops Passive Backplane with 2 Loop Resiliency Circuit (LRC) I/O Module. FC-AL DB9 cables Maximum external cable length: Tx/Rx - 30m Tx only (daisy chain) - 15m MIA supported Tx/Rx connector only 1.4.7...
  • Page 22 SS-1200-FCAL User Guide...

  • Page 23: Getting Started

    Getting Started Chapter 2 Getting Started 2.1 Introduction In this chapter, you are shown how to install your SS-1200-FCAL Enclosure and plug-in modules into an industry standard 19 inch rack cabinet. Caution When connecting up the SS-1200-FCAL subsystem, use only approved power cords. 2.2 Planning Your Installation Before you begin installation you should become familiar with the configuration requirements of your SS-1200- FCAL system, detailed in...
  • Page 24 SS-1200-FCAL User Guide Table 2–1 SS-1200-FCAL Configuration Module Location I/O Modules The Primary Module must be fitted in Bay 3/1. A second module (providing a second loop path to all drives) may be fitted in Bay 3/3. ESI/Ops Panel (variants •...

  • Page 25: Enclosure Bay Numbering Convention

    Getting Started 2.2.1 Enclosure Bay Numbering Convention The enclosure bay numbering convention is shown in Figure 2–1. A Bay is defined as the space required to house a single 1.6" high 3.5 inch disk drive in its carrier module. e.g. a 1 x 3 bay module would take the space of 1 drive width by 3 drive bays high (in the rack mount configuration).

  • Page 26: Chassis Installation

    SS-1200-FCAL User Guide Figure 2–2 Rack Mounting Rail kit 2.3.2.1 Parts Check List • Rack Mounting Rail Kit. 2.3.2.2 Installation Procedure Please see detail drawings supplied with the rack mounting rail kit for assembly details. 2.3.3 Chassis Installation 2.3.3.1 Parts Check List •...

  • Page 27: Power Supply/Cooling Module Installation

    Getting Started If supplied, fit the rear hold down brackets at the rear of the unit (4 screws) do not tighten. Screw the 4 front rack mount screws through the flanges and tighten. If supplied, tighten the rear hold down bracket ensuring the bracket is in tight contact to both the side and top of the chassis to avoid any movement of the chassis in the rack.
  • Page 28 SS-1200-FCAL User Guide PSU/Cooling Module Bay Figure 2–4 Power Supply/Cooling Module Location (Bay 4 shown) Hold the latch while pushing the module gently home into the bay, ensure that it is fully engaged and that the retention latches are engaged into the chassis (See Figure 2–5).

  • Page 29: Esi/Ops Panel Module Installation

    Getting Started Figure 2–6 Fitting the Earth Screw 2.3.5 ESI/Ops Panel Module Installation 2.3.5.1 Parts Check List • Front ESI/Ops Panel Module OR Rear ESI/Ops Panel Module • Ops panel key(s) • Jumper 2 pin 2.3.5.2 Manual Spin-up Jumper This jumper is provided to disable the auto spin start function. Caution If this jumper is fitted the Enclosure services will not attempt to auto start any of the drives in the enclosure.
  • Page 30 SS-1200-FCAL User Guide Manual Spin up Jumper Figure 2–7 Manual Spin -up Jumper Figure 2–8 Installing the ESI/Ops Panel (Front Mounting)
  • Page 31 Getting Started Figure 2–9 ESI/Ops Panel: Front Installation Figure 2–10 Installing the ESI/Ops Panel (Rear Mounting) 2.3.5.4 ESI/Ops Panel Installation Procedure Caution Check that the Ops panel keys are included with the module. If they cannot be accounted for they may have been discarded with the packaging.

  • Page 32: Other Plug-In Modules

    SS-1200-FCAL User Guide Figure 2–11 ESI/Ops Panel: Rear Installation 2.3.6 Other Plug-in Modules Please refer to the relevant SS-1200-FCAL Installation Guides for information on the ILRC I/O Module and Drive Carrier Module installation procedures. Important Ensure that all plug-in modules are installed BEFORE fitting blanking plates (see Section.2.3.8). 2.3.7 Interface Cabling Please refer to the SS-1200-FCAL LRC I/O Module Installation manual for details of interface cable attachments.

  • Page 33: Power Cord Connection

    Getting Started 2.3.8.1 Parts Check List where applicable: • Single bay Rear Blank plates • 1x2 bay Rear Blank plates • 1x3 bay Rear Blank plates Operation of the enclosure with ANY blank plates or rear modules missing will disrupt the airflow Warning and the drives will not receive sufficient cooling.
  • Page 34 SS-1200-FCAL User Guide...

  • Page 35: Operation

    Operation Chapter 3 Operation 3.1 Before You Begin Before powering up the enclosure please ensure that all the modules are firmly seated in their correct bays and that Blank plates are fitted in any remaining bays. 3.2 Power On Do not operate the subsystem until the ambient temperature is within the specified operating range. If the drives have been recently installed ensure they have had time to acclimatize before operating them.

  • Page 36: Run Mode (Normal Operation)

    SS-1200-FCAL User Guide Notes All LEDs on the Ops panel should be lit Green at power up to indicate that the system is functioning correctly. (The UPS LED will be lit Green with or without UPS fitted.) If any alarms sound shortly after power on then a problem exists and the procedure in , ”Troubleshooting and Problem Solving”...

  • Page 37: Starting The Drives

    Operation Under Normal conditions the following LEDs should all be illuminated constant GREEN LED Indicators Symbol System Status Drive Status Power & Cooling Status UPS Status Power Standby Status Switches • Push-button Audible Alarm Mute • Push-button Standby/Operational switch • Rotary Keylock - Run/Service activate If a problem is detected the ESI processor will change the color of the relevant LED to AMBER.

  • Page 38: Disk Drives Leds

    SS-1200-FCAL User Guide • The 'Manual start' option jumper has been fitted to the ESI/Ops panel module during installation, thus disabling the drive auto start function. If manual start has been selected, then Drive Start commands must be issued to each drive in order to start their motors •...

  • Page 39: Troubleshooting And Problem Solving

    Troubleshooting Chapter 4 Troubleshooting and Problem Solving 4.1 Overview The SS-1200-FCAL Enclosure includes a processor and associated monitoring and control logic to enable it to diagnose problems within the enclosure’s power, cooling and drive systems. The Enclosure Services Processor is housed along with the Operator Panel either in the front or rear of the enclosure. The sensors for power, cooling and thermal conditions are housed within the Power Supply/Cooling modules.

  • Page 40: Audible Alarm

    SS-1200-FCAL User Guide Table 4–1 Ops Panel LED Status Green Steady Green/Amber Amber Steady Section Flashing Ref No. Power/ Cooling Power off/ All PSUs & Fans Not Used Any PSU or Fan 4.5.2 Standby fault UPS Status Not used on FC-AL Enclosure Standby No AC supply Standby OR...

  • Page 41: Audible Alarm Mute

    Troubleshooting 4.3.1 Audible Alarm Mute When the Audible Alarm sounds, it may be muted by pressing the Alarm Mute push-button until a double beep is heard (approximately 1 second). The Alarm Mute push-button is located beneath the indicators on the Operator Panel (see Figure 4–1).

  • Page 42: Power Supply/Cooling Faults

    SS-1200-FCAL User Guide 4.5.2 Power Supply/Cooling Faults Symptom Cause Action 1 Operator Panel Power 1 Any power fault. 1 Check Power On/Off Switch on rear of Supply/Cooling LED Power Supply/Cooling module is 2 A fan failure. AMBER (~ and Fan switched ON.(not accessible on later Symbol).

  • Page 43: Thermal Alarm

    Troubleshooting 4.5.4 Thermal Alarm Symptom Cause Action 1 Operator Panel Power If the internal temperature 1 Check local ambient environment Supply/Cooling LED measured in the airflow through temperature is below the upper 40°C AMBER (~ and Fan the enclosure exceeds a pre-set specification.

  • Page 44: Fc-Al Drive Carrier Module Faults

    SS-1200-FCAL User Guide 4.6 FC-AL Drive Carrier Module Faults Disk drive status is monitored by a Green LED and an Amber LED mounted on the front of each Drive Carrier Module, providing the following indications: Condition Status Action GREEN • No drive fitted •...

  • Page 45: Power Supply/Cooling Module

    Troubleshooting 4.9.1 Power Supply/Cooling Module 4.9.1.1 Removing the Module Warning Do not remove the faulty Power Supply/Cooling module unless you have a replacement unit of the correct type ready for insertion. If a power supply unit or its fan is faulty, you must replace the whole power supply/cooling module. If you have two or three power supply units installed, you can continue working while replacing the faulty module.

  • Page 46: Esi/Ops Panel Module

    SS-1200-FCAL User Guide Figure 4–3 Fitting the Grounding Screw 4.9.2 ESI/Ops Panel Module 4.9.2.1 Removing the Module Important This module is designed for Hot Plug replacement. In order to ensure that there is no loss of system availability during replacement, the enclosure DEFAULT state with the ESI module removed is Power On.

  • Page 47: List Of Spare Parts And Ancillary Items

    Troubleshooting 4.9.2.2 Inserting the Module Install the module by sliding into the correct bay (1/1 at front or 3/1 at rear) ensuring the module has docked with the connector and the retention clip has engaged with the chassis. (Figure 4–5) Caution TheESI/Ops panel module variants are not interchangeable, a front mountied module cannote be installed in the rear mounting position and vice versa.
  • Page 48 SS-1200-FCAL User Guide...

  • Page 49: Glossary

    Glossary Glossary In glossary definitions, italics are used for items defined elsewhere in the glossary and bold is used for the items shown in brackets after the main heading of the entry. ASCII American Standard Code for Information Interchange. A 7-bit binary code (0’s, 1’s) used to represent letters, numbers, and special characters such as $,!, and /.
  • Page 50 SS-1200-FCAL User Guide Hot swap Hot swapping is the term used for manually swapping a failed disk unit with a replacement while the SS-1200-FCAL subsystem is in normal use. Hz (Hertz) a frequency measurement unit used internationally to indicate cycles per second. Initialize To prepare a hardware device for use.

  • Page 51: Index

    Index Index AC Mains 33 fan failure 32, 33 Alarm Mute 8, 31, 34 Alarm Mute push-button 31 Anti-tamper lock 9 Audible Alarm 5, 8, 30, 31, 32, 33 Hot Plug 36 auto spin start 6, 19 auto start 28 I/O Module 13, 14, 22, 37 IEC 320 connector 23 Backplane 1, 7, 15, 34, 37...
