Specifications

Item
Dimensions
Weight
Maintenance clearance
AC line voltage (US)
AC line voltage
(International)
Power consumption
Recommended room temperature
Recommended room humidity
Heat dissipation

System Configuration Summary

Feature
Processors
Bus Speed
Memory Modules
Memory Style
Memory Type
Memory Speed
Memory Size
Memory Expansion
Graphics
Audio
Networking
SCSI
Specifications
16.7 in wide x 8.7 in high x 23.6 inches deep
42.4 cm wide x 22.1 cm high x 60.0 cm deep
55 LB. (25 kg) fully configured
36 inches (91.4 cm) front and back
90 - 132 VAC, 47 - 63 Hz, 1 phase, 15A/125 V receptacle
180 - 264 VAC, 47 - 63 Hz, 1 phase, 15A/250 V receptacle
780 W (based on 6.5 A, 120 VAC, 60 Hz)
50 to 80 F (10 to 26 C)
20% to 80% (non-condensing)
2,662.14 BTU/hr
Description
Dual Intel Pentium II (450 MHz) or Pentium III (500 MHz or higher)
100 MHz
Dual inline memory modules (DIMMs), six banks, one DIMM per bank,
non-interleaved
168-pin SDRAM DIMM, 10 ns, 3.3V, registered, 72 bit (non-ECC)
168-pin SDRAM DIMM, 10 ns, 3.3V, unbuffered, 72 bit (ECC)
Synchronous Dynamic Random Access Memory (SDRAM)
100 MHz
64 MB minimum, 3 GB maximum
64 MB, 128 MB, 256 MB, or 512 MB increments
Varies by system
Integrated Ensoniq ES1371 AudioPCI controller; additional audio
controller varies by system
One integrated 10/100 Mbps, PCI bus-mastering, ACPI and PC97
compliant Ethernet adapter, with Wake-On-LAN support
One integrated dual-channel, 16-bit, LVDS Wide Ultra2 SCSI bus for
internal SCSI devices
One integrated single-channel, 8-bit, Narrow Ultra SCSI bus for internal
and external SCSI devices
