Intergraph ErgoView Stand Installation Manual

Ergoview stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ErgoView Stand
Installation Guide
March 1998
DFED3607M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ErgoView Stand and is the answer not in the manual?

Questions and answers

Related Manuals for Intergraph ErgoView Stand

Summary of Contents for Intergraph ErgoView Stand

  • Page 1 ErgoView Stand Installation Guide March 1998 DFED3607M...
  • Page 2 All warranties given by Intergraph Computer Systems about equipment or software are set forth in your purchase contract. Nothing stated in, or implied by, this document or its contents shall be considered or deemed a modification or amendment of such warrantites.

  • Page 3: Table Of Contents

    Contents 1 ErgoView Stand Installation..................1 2 Unpacking the Digitizing Table and Base ...............2 3 Unpacking the ErgoView Stand ................4 4 Installing the Monitor ....................5 CLIX Workstation Monitor....................5 Removing the Swivel Base................5 Installing a 19-, 20-, or 21-inch Monitor ............5 Installing a 27-inch Monitor ................5 Hitachi OEM Monitor....................6...

  • Page 5: Ergoview Stand Installation

    Damage may occur to this equipment if installed in a factory or shop environment where oil, dust, or other airborne contaminants are present. To unpack and install the digitizing table, ErgoView stand, and monitor, you will need the help of one person, and the following tools and equipment:...

  • Page 6: Unpacking The Digitizing Table And Base

    Unpacking the Digitizing Table and Base The digitizing table and base are shipped already assembled together. If your installation site has an existing digitizing table with an Intergraph Computer Systems or Hamilton table base, go to “Unpacking the ErgoView Stand.”...
  • Page 7 11. With a person at each side of the table, carefully roll the digitizing table down the ramps. 12. Place the digitizing table in the area where you will be installing the ErgoView stand. WARNING Do not connect the power cable to the AC power outlet at this time.

  • Page 8: Unpacking The Ergoview Stand

    9. Place the stand near a wall outlet. Allow 36 inches of clearance at the back of the stand for operator and service access. WARNING Do not connect the power cable to the AC power outlet at this time. CAUTION The ErgoView stand must be connected to an unobstructed AC power wall outlet. See “Installing the Monitor“ to continue.

  • Page 9: Installing The Monitor

    180 degrees, and remove the remaining two screws. 6. Remove the swivel base. Installing a 19-, 20-, or 21-inch Monitor 1. Lock the ErgoView stand tilt adjustment knob, located where the monitor collar attaches to the ErgoView stand. 2. Set the monitor into the collar.

  • Page 10: Hitachi Oem Monitor

    (attached to the bottom of the collar) and into the monitor housing. 6. Tighten all screws. See “Connecting the Cables” to finish setting up the ErgoView stand. Hitachi OEM Monitor The hardware kit (MKIT120) used to install the Hitachi monitor contains the following items:...

  • Page 11: Replacing The Monitor Collar

    2. Secure the adapter bracket to the monitor using the two screws removed from the swivel base. Replacing the Monitor Collar The monitor collar shipped on the ErgoView stand is designed for CLIX workstation monitors only. You must replace this collar with the one in the mounting kit before installing the Hitachi OEM monitor.

  • Page 12: Panasonic Oem Monitor

    4. Thread the four M4x8mm Phillips flat head screws through the bottom of the cover plate and into the monitor housing and tighten all screws. See “Connecting the Cables” to finish setting up the ErgoView stand. Panasonic OEM Monitor The hardware kit (MKIT157) used to install the Panasonic monitor contains the following items:...

  • Page 13: Preparing The Monitor For Installation

    Before the monitor can be installed, it must be prepared for installation by removing the monitor cover and swivel base, and attaching the adapter bracket included with the kit. Finally, the separator plate from the previous monitor must be attached to the adapter bracket. Preparing the Monitor for Installation WARNING The monitor is heavy and could cause serious personal injury if dropped.
  • Page 14 5. Firmly press down and pull out the press tabs on the swivel base. Press Tabs Swivel Base 6. Remove the swivel base from the monitor by sliding it to the back of the monitor.
  • Page 15 7. Place the adapter bracket (MMSA408) onto the bottom of monitor. Ensure the holding latches are secured inside the slots in the monitor frame. Adapter Bracket Slot 8. Slide the bracket toward the front of the monitor to secure it in place. The bracket sn aps in without using screws.

  • Page 16: Replacing The Monitor Collar

    Filler Bracket Replacing the Monitor Collar The collar shipped on the ErgoView stand is designed for CLIX workstation monitors only. You must replace this collar with the one in the mounting kit before installing the Panasonic OEM monitor. 1. Remove the tilt adjustment knob, located where the monitor collar attaches to the ErgoView stand.

  • Page 17: Installing The Monitor

    8. Using four six-inch pieces of the one-inch wide adhesive tape (CPTP076), attach the cover plate (CFAB325) to the underside of the aluminum plate. Collar Aluminmun Plate Tape Cover Plate Installing the Monitor CAUTION Ensure the new collar is completely secure in the stand before installing the OEM monitor. 1.
  • Page 18 4. Attach the blanking plate to the collar above the monitor. Use the washers (CPHM129) and nuts (CPHM048) to secure the plate to the collar. Blanking Plate Filler Bracket See “Connecting the Cables” to finish setting up the ErgoView stand.

  • Page 19: Connecting The Cables

    WARNING Never connect a digitizing table base to an AC power wall outlet when used with the ErgoView stand. The digitizing table base must be connected to the ErgoView stand for safe operation. This will ensure power shutdown to the table base in case of an obstruction.
  • Page 20 CAUTION When connecting cables from a digitizing table base to the ErgoView stand, always use the AC receptacle on the front of the ErgoView stand. This will ensure power shutdown to the table base in case of an obstruction.
  • Page 21 4. Connect one end of the AC power cord (CWIR378) to the top AC receptacle on the back of the ErgoView stand. Connect the other end of the AC power cable to an unobstructed AC power wall outlet. AC Power...

  • Page 22: Dual Ergoview Stands

    Logic Interconnect Cable Second Stand First Stand 2. Remove the cover from the receptacle labeled 120V, 5A, on the back of the first ErgoView stand. Connect the AC power interconnect cable to the 120V, 5A receptacle. 120V, 5A AC Power...
  • Page 23 At this point, the stand cannot be lowered until the circuitry is reset. To reset the circuitry, press the hand-held control cable switch to first raise the stand. Remove the obstruction if present; then lower the ErgoView stand. See the system’s hardware documentation to connect other cables and to start the system.

  • Page 24: Replacing A Clix Workstation Monitor

    1. Disconnect the power cord from the CLIX workstation monitor and the AC power outlet. 2. Using a No. 2 Phillips screwdriver, remove and retain the screws that secure the CLIX workstation monitor to the ErgoView stand. The screws are located underneath the monitor. 3. Remove the monitor and set it aside.
