Before You Begin

WARNING Disconnect the system and peripheral devices from AC power before servicing
internal components! Failure to remove AC power may result in equipment
damage or personal injury. The GT RAX system is always on when connected
to AC power.
WARNING There is a danger of explosion if the battery is incorrectly replaced.
WARNING Follow all warnings and cautions in the servicing instructions. If you fail to
follow documented procedures, personal injury and damage to equipment can
result.
CAUTION Use an antistatic wrist strap for all servicing procedures to avoid the possibility of
electrostatic discharge.
CAUTION Do not overtighten screws and other fasteners to avoid damaging threads.
CAUTION Follow all warnings and cautions in these servicing instructions. If you fail to follow
documented, approved procedures, personal injury or damage to equipment can
result.
See Chapter 1, "Accessing the Components," for details on opening the system and protecting
against electrostatic discharge. These procedures assume you have removed the cover from the
system. "Right side" and "left side" are as seen from the front of the unit. After servicing the
system, replace panels as described in Chapter 1, "Accessing the Components."

Base Unit Components

The following figure shows the base unit components that can be replaced:
Disk Drive
Bay Door
Top Cover
Face Panel
