Supported Ports

The XSR supports the following port types:
• Single-channel ports: Fast- and GigabitEthernet, Sync/Async serial, ATM
• Multiple-channel type ports: BRI, T1/E1

Numbering XSR Slots, Cards, and Ports

The syntax for XSR slot, card, and port numbering on the CLI, illustrated in
slot#/card#/port#
These parameters indicate:
• slot #: (motherboard is zero), (XSR 1800: 1/2, 3020/3150: 1/2, 3250: 0-2)
• card #: NIM card number (FastEth: 1/2, GigaEth: 1-6 from left to right)
• port #: NIM port numbers begin with zero
Slot, cards, and ports on the motherboard (Slot 0) are expressed as:
• Slot 0, Card 1 or 2, Port 1 or 2:
ignored
Slot, cards, and ports on the first XSR-3250 upper tray slot are expressed as:
• Slot 1, Card 1 or 2, Port 1-4:
Slot, cards, and ports on the second XSR-3250 upper slot are expressed as:
• Slot 2, Card 1 or 2, Port 1-4:

Setting Port Configuration Mode

The configuration mode setting for ports on the XSR is as follows:
• Single-channel ports are configured in Interface configuration mode.
• Multi-channel ports are configured in Controller configuration mode. A physical layer data
stream is identified by channel using the
then configured using the

Setting Interface Type and Numbering

XSR interface types and numbers are set as follows:
• Physical-type interface and port numbers are similar. Interface types are Serial BRI, ATM, PRI
(T1/E1), or Fast/GigabitEthernet.
Figure 2-2 Slots on the XSR-3250
Slot 1
Slot 0
0/1/1-4
1/1/1-4 and
2/1/1-4 and
interface
Motherboard
or 1/1-4 and 0/2/1-4
1/2/1-4
2/2/1-4
controller command, and this channel group is
command.
Utilizing the Command Line Interface
Figure 2-2, is:
Slot 2
or 2/1-4 . The first 0 can be
XSR User's Guide 2-17
