Table B-34 etsysVpnIntfPolicyTable
Field
etsysVpnIntfPolicyName
etsysVpnIntfPolicyDFHandling
etsysVpnIntfPolicyRowStatus

etsysVpnIpsecPolicyRule Table

This table defines the IPSec policy rules. The table index is {etsysVpnIpsecPolicyName,
etsysVpnPolRulePriority}.
Table B-35 etsysVpnIpsecPolicyRuleTable
Field
etsysVpnIpsecPolRulePriority
etsysVpnIpsecPolRulePeerAddrType
etsysVpnIpsecPolRulePeerAddress
etsysVpnIpsecPolRuleCommonSA
etsysVpnIpsecPolRuleMode
etsysVpnIpsecPolRuleSelectorId
etsysVpnIpsecPolRuleRowStatus

etsysVpnIpsecPolProposals Table

This table links IPSec proposals in the etsysVpnIpsecProposalTable with IPSec policy rules in the
etsysVpnIpsecPolRuleTable. The XSR implementation permits a maximum of six proposals and
priority values 1, 2, 3, 4, 5, or 6 only. Be aware that the lower priority row must exist before a
higher priority proposal can be created; that is, if no priority row equals 1, then priority rows 2
through 6 cannot be created. Also, be advised that a proposal in the etsysVpnIpsecProposalTable
must exist before the corresponding row can be created in this table. The table index is
{etsysVpnIpsecPolicyName, etsysVpnIpsecPolRulePriority, etsysVpnIpsecPolPropPriority}.
Table B-36 etsysVpnIpsecPolProposalsTable
Field
etsysVpnIpsecPolPropPriority
etsysVpnIpsecPolPropProposalName
etsysVpnIpsecPolPropRowStatus
Description
The name of an IPSec policy. When used to create a row, all other
values are defaulted.
When used to create a row, all other values are defaulted.
Acceptable values are active(1) and destroy(6).
Description
The priority of the rule, equivalent to the sequence number from
the CLI commands.
This InetAddressType object is required for future compatibility
with IPv6. For the XSR, this can only be set to IPv4. When used to
create a row, all other values are defaulted.
Since the address type is IPv4, this is always a 4-octet IP address.
When used to create a row, all other values are defaulted.
When used to create a row, all other values are defaulted.
Acceptable values: tunnel(1) and transport(2). When used to
create a row, all other values are defaulted.
On the XSR, this is an ASCII string representing an access group,
e.g. 100. When used to create a row, all other values are defaulted.
Acceptable values: active(1), createAndGo(4) and destroy(6).
When used to create a row, all values are defaulted.
Description
An index value for the proposal.
A proposal name from the etsysVpnIpsecProposalTable. This
object must be used to create the row.
Acceptable values: active(1) and destroy(6). This object cannot be
used to create a row since the proposal name is needed first.
VPN MIB Tables
XSR User's Guide B-15
