Implementing Dial Services

Configuring the Dialer Interface

The following tasks need to be performed to configure a dialer profile:
• Create and configure the dialer interface
• Configure a map class (optional but distinguishes dialer profiles)
• Configure a physical interface for the dialer interface

Creating and Configuring the Dialer Interface

1. Enter interface dialer number to create the dialer interface.
The number range is 0 to 255.
2. Enter encapsulation ppp to enable PPP encapsulation.
3. Enter dialer pool number to specify the dialer pool.
The number range is 0 to 255.
4. Enter dialer string <dialstring> class <classname> to specify the remote destination string to be
used.
The string is normally a 10-digit telephone number.
10-10 Configuring Dialer Services
Figure 10-6 Dialer Profile of Destination (987) 231-2345
Network
Interface dialer 0
ip address 10.1.1.1 255.0.0.0
encapsulation ppp
dialer string 4161234456 class Toronto
dialer string 9872312345 class Andover
dialer pool 6
map class dialer Andover
wait for carrier 30
Dialer Pool 6
contains two ports:
Serial 1/1 and Serial 1/2
Serial 1/1 is preferred
(has a higher priority)
Serial 1/1
dialer pool member 6 priority 200
Serial 1/2
dialer pool member 6 priority 140
10.1.1.1/8
Dialer profile for destination
9872312345 uses the map
class Andover and one port
belonging to pool 6
