– DOS-style full path (without the file name) of the site of the Bootrom file on the host PC.
– The username and password to use when connecting to your FTP server on the host PC.
6. Verify the network boot values using the
sn
XSR:
Local IP address
Remote IP address : 192.168.1.2
Remote file path
Transfer Protocol : FTP
Ftp userid
Ftp password
Local target name : XSR
Autoboot
Quick boot
Current 405 ethernet MAC address is: 00:01:f4:00:01:02
Current PCI ethernet MAC address is: 00:01:f4:01:01:03
Type b to list the boot command group.
7.
Enter the bU command to transfer the Bootrom image file over FTP and upgrade the Bootrom
8.
flash sectors to the latest version. Be sure to enter the command with an uppercase U and
follow the prompts.
Caution: If the Bootrom file transfer is corrupted due to a network interruption, this step may
render the router unusable. If you suspect this has happened, type n at the confirmation prompt to
abort erasing and replacing the Bootrom. Then, delete the file (type: rm bootrom1_21.fls, for
example) and re-issue the bU command to transfer the image again. Here is a sample session:
bU bootrom_uncmp.fls
XSR1800:
ftp RETR 192.168.1.2:c:/XSR1850/ bootrom_uncmp.fls into
flash bootrom_uncmp.fls
........ Saved 818448 bytes to flash: bootrom_uncmp.fls
Checking bootrom_uncmp.fls...
Updating bootrom with file, "bootrom_uncmp.fls".
Proceed with erasing current Bootrom in flash and replace with
bootrom_uncmp.fls? (y/n)
*****************************************************
* Do not interrupt or power down until complete!
*****************************************************
Erasing 3 sectors at address=0xfff20000
Programming 131072(0x20000) bytes at address 0xfff20000
Programming 131072(0x20000) bytes at address 0xfff40000
Programming 48299(0xbcab) bytes at address 0xfff60000
Verifying Bootrom flash sectors
Locking 3 Bootrom flash sectors
Second copy of Bootrom ...
Erasing 3 sectors at address=0xfff80000
Programming 131072(0x20000) bytes at address 0xfff80000
sn
: 192.168.1.1
: c:/XSR
: administrator
: anonymous
: enabled
: no
y
Utilizing the Command Line Interface
command. For example:
*
