Understanding ISDN
–
18 Channel Id. 81
6C Calling number N0:2800
70 Called number N0:2500
The succeeding section lists all message types and IEs the XSR displays. All unsupported message
types and IEs are marked UNKNOWN or IE not Found.
Table 11-1 Q931 Decoding
Message #
0x00
0x01
0x02
0x07
0x0f
0x03
0x05
0x0d
0x23
0x2f
0x23
0x26
0x2e
0x22
0x25
0x2d
0x21
0x20
0x45
0x4d
0x5a
0x46
0x4e
0x60
0x79
0x7b
0x62
0x6e
0x7d
11-8 Configuring Integrated Services Digital Network
+
Next line: 04 Bearer capability 8890
Message Type
NATIONAL
ALERT
CALL PROC
CONNECT
CONNECT ACK
PROGRESS
SETUP
SETUP ACK
MODIFY
MODIFY COMP
MODIFY REJ
RESUME
RESUME ACK
RESUME REJ
SUSPEND
SUSPEND ACK
SUSPEND REJ
USER INFO
DISCONNECT
RELEASE
RELEASE COMPL
RESTART
RESTART ACK
SEGMENT
CONGESTION
INFO
FACILITY
NOTIFY
STATUS
IE # Information Element
0xA1 Sending complete
0xA0 More Data
0x04 Bearer capability
0x08 Cause
0x10 Call identity
0x14 Call state
0x18 Channel Id.
0x1C Facility
0x1E Progress indicator
0x20 Net specific facility
0x27 Notification indicator
0x28 Display
0x29 Date/time
0x2C Keypad facility
0x34 Signal
0x36 Switch hook
0x38 Feature activation
0x39 Feature indication
0x40 Information rate
0x42 End-to-end transit delay
0x6C Calling number
0x6D Calling subaddress
0x70 Called number
0x71 Called subaddress
0x74 Redirecting number
0x78 Transit Network
0x79 Restart indicator
0x7C Low layer compatibility
0x7D High layer compatibility
