Enterasys X-PEDITION E9.1.7.0 Release Notes

System firmware version e9.1.7.0
Hide thumbs

Advertisement

Quick Links

Download this manual
INTRODUCTION:
This document provides specific information relevant to version E9.1.7.0 of the System Firmware for the X-Pedition
family of products. It includes content from the E9.0.7.7 System Firmware Maintenance Release and the E9.1.3.0A
patch release.
Enterasys Networks recommends that these Release Notes be thoroughly reviewed prior to the
installation or upgrade of this product.
GLOBAL SUPPORT:
Enterasys Networks Global Technical Assistance Center
By Phone: (603) 332-9400
By Email:
Support@enterasys.com
By Web:
http://www.enterasys.com/support
By Fax:
(603) 337-3075
By Mail:
Enterasys Networks, Inc.
35 Industrial Way
P.O. Box 5005
Rochester, NH 03866-5005
For information regarding the latest firmware available, recent releases note revisions, or if you require additional
assistance, please visit the Enterasys Networks Support web site.
10/02/03 P/N: 9038090-53
F0615-J
X-Pedition Router
System Firmware Version E9.1.7.0
System Firmware Release Date: September 2003
Subject to Change Without Notice
50 Minuteman Rd.
Andover, MA 01810
USA
Tel: (978) 684-1000
CUSTOMER RELEASE NOTES
Page: 1 of 31

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-PEDITION E9.1.7.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Enterasys X-PEDITION E9.1.7.0

Summary of Contents for Enterasys X-PEDITION E9.1.7.0

  • Page 1 This document provides specific information relevant to version E9.1.7.0 of the System Firmware for the X-Pedition family of products. It includes content from the E9.0.7.7 System Firmware Maintenance Release and the E9.1.3.0A patch release. Enterasys Networks recommends that these Release Notes be thoroughly reviewed prior to the installation or upgrade of this product. GLOBAL SUPPORT:...
  • Page 2 SYSTEM FIRMWARE SPECIFICATION: Before installing the E9.1.7.0 System Firmware, the Boot Firmware should be upgraded to at least version E3.2.0.0. Refer to the E3.2.0.0 Boot Firmware Release Notes, or any X-Pedition Getting Started Guide, for instructions on upgrading the Boot Firmware. System Firmware File Name xp9170 xp9078...
  • Page 3 RELEASE NAMING CONVENTION: Normally, the X-Pedition product family supports two active release lines. The older line is always in maintenance only mode and receives only maintenance improvements—the newer line receives maintenance improvements and introduces new features. For a brief time, however, the X-Pedition will support a special third line—E9.0.8. This line introduces the Security Attack Monitor (SAM) feature on the E9.0 code base.
  • Page 4 RELEASE NAMING CONVENTION A release line is defined by the first two digits in the name, e.g. E9.0 and E9.1. The third digit increments with each release during the development phase of a line. For example, E9.0.7.0 is the seventh development release for the E9.0 line.
  • Page 5 NOTE: In some cases, the Minimum System Firmware Version depends upon the revision of a particular model number. The revision number appears on the serial number sticker attached to the front of all Enterasys Networks hardware assemblies. These numbers are interpreted as follows:...
  • Page 6 This version of System Firmware supports the X-Pedition Router hardware listed in the following table: Part 5SSRM-02 Router module for the Matrix E5 6SSRLC-FX-AA 8-port 100BASE-FX (MT-RJ) module for 5SSRM-02 and 6SSRM-02 6SSRLC-LX-AA 2-port 1000BASE-LX module for 5SSRM-02 and 6SSRM-02 6SSRLC-LX70-AA 1-port 1000BASE-LX 70 KM module for 5SSRM-02 and 6SSRM-02 6SSRLC-SER-AA...
  • Page 7 Part SSR-2-LX70 1-port 70 km 1000BASE-LX module for X-Pedition 2000 SSR-2-LX70-AA 1-port 70 km 1000BASE-LX module for X-Pedition 2000 SSR-2-SER 2-port Serial module (No compression or encryption) for X-Pedition 2000 SSR-2-SER-AA 2-port Serial module (No compression or encryption) for X-Pedition 2000 SSR-2-SERC 4-port Serial module with compression (No encryption) for X-Pedition 2000 SSR-2-SERC-AA...
  • Page 8 Part SSR-HTX32-16 16-port 10/100 TX module (Cat 5 RJ-45) with 16 MB [T-Series] for X-Pedition 8000/8600 SSR-MEM-128 128MB Memory Upgrade Kit for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, and ER16-CM3-128 SSR-MEM-256 256MB ECC Memory Upgrade Kit for SSR-CM4-256 and ER16-CM4-256 SSR-PCMCIA 8MB PCMCIA card for SSR-CM2-64, SSR-CM2-128, SSR-CM3-128, SSR-CM4-256, ER16-CM3-128, and ER16-CM4-256 35-028-01 35-053-01...
  • Page 9 Part XP-2-LX70-AA 1-port 70 km 1000BASE-LX module for X-Pedition 2400 XP-2-SER-AA 2-port Serial module (No compression or encryption) for X-Pedition 2400 XP-2-SERC-AA 4-port Serial module with compression (No encryption) for X-Pedition 2400 XP-2-SERCE-AA 4-port Serial module with compression and encryption for X-Pedition 2400 XP-2-SX-AA 2-port 1000BASE-SX module for X-Pedition 2400 XP-2-TX-AA...
  • Page 10 The following table lists supported hardware that is System Firmware and Boot Firmware version independent. Part APHY-21 SSR-ATM29-02 1 port OC-3 MMF Physical Interface Module APHY-22 SSR-ATM29-02 1 port OC-3 UTP Physical Interface Module APHY-29IR SSR-ATM29-02 1 port OC-3 SMF-IR Physical Interface Module APHY-67 SSR-ATM29-02 1 port DS-3/T3 Physical Interface Module (Coax) APHY-77...

  • Page 11: Hardware Requirements

    HARDWARE REQUIREMENTS TABLE: NOTE: X-Pedition line card hardware makes use of three basic ASIC versions (pre AA-series, AA-series and T- series). The features supported by each line card are roughly defined by which series of ASIC hardware is used on that card. The following table shows the hardware supporting specific features in this release: X-Pedition Description...
  • Page 12 X-Pedition Description Feature Set / Part Number XP 2400 XP-2400 X-Pedition 2400 XP-2-ATM29-02 2-port ATM OC-3 XP-2-FX-AA 8-port 100BASEFX XP-2-HSSI-AA 2-port HSSI XP-2-LX-AA 2-port 1000BASE-LX XP-2-LX70-AA 1-port 70 km 1000BASE-LX XP-2-SER-AA 2-port Serial XP-2-SERC-AA 4-port Serial, compression 4-port Serial, compression & XP-2-SERCE-AA encryption XP-2-SX-AA...
  • Page 13 X-Pedition Description Feature Set / Part Number 4-port Serial, compression & SSR-SERCE-04 encryption 4-port Serial, compression & SSR-SERCE-04-AA encryption ER16 ER16-04 4-port 1000BASE GBIC ER16-08 8-port 1000BASE GBIC ER16-ATM29-02 2-port ATM OC3 ER16-FDDI-02 2-port FDDI ER16-GTX32-04 4-port 1000BASE-TX ER16-GTX32-08 8-port 1000BASE-TX ER16-HFX31-24 24-port 100BASE-FX (MMF) ER16-HFX39-24...
  • Page 14 NETWORK MANAGEMENT SOFTWARE SUPPORT: The following table displays information on the Network Management Software that supports this release: NMS Platform NetSight Element Manager NetSight Atlas Console NetSight Atlas Console Lite NetSight Atlas Inventory Manager NetSight Atlas Router Services Manager NOTE: Network Management Software may not utilize the latest features in the System Firmware. Enterasys Networks recommends reviewing the release notes included with the user’s specific Network Management Platform for more information.

  • Page 15: Password Recovery

    INSTALLATION AND CONFIGURATION NOTES INSTALLATION AND CONFIGURATION NOTES: Password Recovery If an X-Pedition password is lost and the user is unable to log in or enter Enable mode, please refer to the Enterasys Global Knowledgebase at http://knowledgebase.enterasys.com/esupport/ Click Search by ID and enter TK0306-9.
  • Page 16 NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0 NEW FEATURES AND ENHANCEMENTS IN E9.1.7.0: NEW FIRMWARE SUPPORT The E9.1.7.0 system firmware provides support for the new features and enhancements below. For more information on any of these enhancements, please see the Enterasys X-Pedition User Reference Manual or Native CLI Reference Manual.
  • Page 17 Display of the System FPGA Revision A capability has been added that permits the display of the system FPGA revision number as illustrated in the example below. SYSTEM# system show hardware Hardware Information System type ER16, Rev. 0 CPU Module type CPU-ER16 (CM4), Rev.
  • Page 18 NEW HARDWARE SUPPORT 10-Gigabit Ethernet (ER16-OS16-01) This release introduces support for the ER16-OS16-01, an optical fiber-based 10-Gigabit Ethernet module for the ER16 platform. This one slot card provides a single modular port of IEEE 802.3ae standards-based connectivity and its optical interfaces are based on fully compliant IEEE 802.3ae SC duplex fiber-optic connectors. Supported interfaces include the following: Part Number Connectivity Description...
  • Page 19 ISSUES RESOLVED IN E9.1.7.0: The following tables provide brief descriptions of the issues resolved in this release. E9.1.7.0 includes all issues resolved in the E9.0.7.7 System Firmware Maintenance Release (see the E9.0.7.7 Release Notes for details). 10-Gigabit Priority queue settings on the ER16-OS26-01 may cause the X-Pedition to experience ingress buffer overflows.
  • Page 20 Hot Swap Under rare circumstances, the system may occasionally core when hot swapping a line card into the router. Internet Protocol (IP) If an X-Pedition with ip enable reverse flow all configured receives an invalid TCP/UDP packet of a specific type, the router may core. Layer-4 An X-Pedition configured with Layer-4 bridging will respond incorrectly to an ICMP request that is not destined for the router.
  • Page 21 Remote Authentication Dial-In Service (RADIUS) An issue was found and corrected that involves users who authenticate through an X-Pedition to a RADIUS server. Contact Enterasys Networks Global Technical Assistance Center for additional information. Remote Monitor (RMON) Packet and byte counts for RMON2 tables are inaccurate.
  • Page 22 Terminal Access Controller Access Control System (TACACS+) An issue was found and corrected that involves users who authenticate through an X-Pedition to a TACACS+ server. Contact Enterasys Networks Global Technical Assistance Center for additional information. 10/02/03 P/N: 9038090-53 F0615-J ISSUES RESOLVED IN E9.1.7.0...
  • Page 23 KNOWN RESTRICTIONS AND LIMITATIONS: Known Restrictions and Limitations are sorted alphabetically by topic heading. 10-Gigabit Ethernet PIM is not currently supported. If a single smarttrunk add ports command contains more than one 10-Gig port, hot swapping one of the ports out of, then back into the router prevents the port from rejoining the SmartTRUNK. Hot swapping an ER16-OS16-01 or ER16-OS26-01 module that belongs to a SmartTRUNK out of the router will disable all ports in the SmartTRUNK.

  • Page 24: Network Management

    Multicast On a non-T-series line card, it is recommended that access ports be used when running a multicast routing protocol such as PIM or DVMRP, due to the fact that multicast packets can be replicated to only one IP VLAN in an 802.1Q trunk port. On a T-series line card, multicast packets will be replicated to multiple IP VLANs in an 802.1Q trunk port.
  • Page 25 Protocol Independent Multicast (PIM-SM) Using the all option of the pim sparse set interface configuration command fails to set the timer options. Users must set these options individually, using each interface name and IP address. Entering the pim sparse set component mrt-spt-mult # command from configuration mode places the command in the router’s active configuration;...
  • Page 26 Erroneously configured static routes may produce a routing loop. As a result, excessive CPU utilization can occur when an improperly configured upstream router sends ICMP redirect messages to a downstream router. It appears this problem has been present in the Enterasys Networks System Firmware since the 2.1.0.0 release.
  • Page 27 COMPLIANCE SUPPORT: Compliance Level Year 2000 IEEE STANDARDS MIB SUPPORT: Standard IEEE 802.3ad LACP IEEE STANDARDS SUPPORT: Standard IEEE 802.1D Spanning Tree IEEE 802.1p Traffic Prioritization IEEE 802.1Q VLAN Trunking IEEE 802.1w Rapid Spanning Tree IEEE 802.3 10 Mbps Ethernet IEEE 802.3ad LACP (Link Aggregation) IEEE 802.3u...
  • Page 28 RFC No. RFC 1350 The TFTP Protocol (Revision 2) RFC 1397 BGP Default Route Advertisement RFC 1483 Multiprotocol Encapsulation over ATM Adaptation Layer 5 RFC 1490 Multiprotocol Interconnect over Frame Relay RFC 1519 CIDR RFC 1552 The PPP Internetwork Packet Exchange Control Protocol (IPXCP) RFC 1570 PPP LCP Extensions RFC 1583...
  • Page 29 IETF STANDARDS MIB SUPPORT: RFC No. RFC 1471 PPP LCP (Link Control Protocol) RFC 1472 PPP Security Protocol RFC 1473 PPP IP NCP (Network Control Protocol) RFC 1474 PPP Bridge NCP RFC 1493 Definitions of Managed Objects for Bridges RFC 1512 FDDI MIB RFC 1595 SONET / SDH MIB...
  • Page 30 ITU-T Q.933 ITU-T I.122/ANSI T1S1 ITU-T Annex D/ANSI T1.617 FDDI STANDARD SUPPORT: Standard ANSI X3T9.5 ANSI X3T9.5/84-49 Rev 7.2 ANSI X3.139-1987 ANSI X3.148-1988 ANSI X3.166-1990 ENTERASYS NETWORKS PRIVATE ENTERPRISE MIB SUPPORT: Title NOVELL-IPX-MIB CTRON-SSR-HARDWARE-MIB CTRON-SSR-POLICY-MIB CTRON-SSR-SERVICE-MIB CTRON-SSR-CAPACITY-MIB CTRON-SSR-CONFIG NOVEL-RIP-SAP-MIB CT-CONTAINER-MIB...
  • Page 31 Enterasys Networks Private Enterprise MIBs are available in ASN.1 format from the Enterasys Networks Support web site at: http://www.enterasys.com/support/mibs/. Indexed MIB documentation is also available. SNMP TRAP SUPPORT: RFC No. RFC 1157 linkDown, linkUp, authenticationFailure Traps RFC 1493 newRoot, topologyChange Traps...
