Figure 1 - 6
Rear View
1.
Vent
2.
DC-In Jack
3.
Serial Port
4.
Parallel Port
5.
External Monitor
(VGA) Port
6.
S-Video-Out Port
7.
PS/2 Type Port
8.
RJ-11 Phone Jack
9.
RJ-45 LAN Jack
1 - 16 Rear View
Rear View
1
2
1
To prevent your computer from overheating make sure nothing blocks the vent/fan
outlet while the computer is in use.
Vent
Vents/fan outlets enable airflow to prevent the notebook from overheating.
DC-In Jack
Plug the supplied AC adapter into this jack to power your notebook.
3
4
5
2
3
4
Overheating
6 7 8
9
5
6 7 8
9
