Rear View

The rear panel of the Notebook Computer offers several ports for the electrical connection to
peripheral devices.

DC-in Socket

This socket is where the Notebook Computer's universal AC/DC power adapter is
connected to the system. To disconnect the power adapter, pull the plug (not the
cord) directly back.

Serial Port

This is a high speed NS16C550 compatible port to connect an external mouse for
example.

Expansion Port

This port is used to connect the proprietary Docking Station. All of the features of
the Docking Station are available through the plug-in process offering the Notebook
Computer access to a desktop system.

RCA Jack

This is an RCA jack to connect a TV set for example.
You may need to select the video standard (NTSC/PAL) for video display.

External Monitor (CRT) Port

This port allows the connection of an external monitor to the system. It uses a 15-
pin connector and supports super-VGA, and Simultaneous display of LCD and
CRT.

MIDI/Game Port

This port is used to either connect any MIDI device such as a MIDI instrument or
keyboard, or connect an external standard joystick.

Parallel Port

This is a parallel port to connect a printer for example. It supports EPP (Enhanced
Parallel Port) and ECP (Extended Capabilities Port) modes, but required as well is
the use of the connected parallel device's software driver.

External Keyboard or PS/2 Mouse Port

An external keyboard is able to be connected to the system via this port. So is an
external PS/2 mouse to the system as another pointing device choice.
